Mini IPTV HD Encoder HD Input IP Output H265 H264 Video Encoder IPTV Streaming Encoder Server
- Category: >>>
- Supplier: Hangzhou Dtvane Technology Co. Ltd.
Share on (60428463560):
Product Overview
Description
Product Category
Product Description
Features:
Support 1 channel HD 1080P+1 channel CVBS input, 2 channels work at the same time.
Support up to 720P, 1080P HD video input
Support image parameter settings
Support HDCP protocol
Supports ONVIF Network Video Protocol
Support streaming resolution settings
Supports MP3 and AAC audio format selection
Support audio output mono and stereo stream switching
Support GOP frame rate settings
Support a click to restore the default configuration
Support STB decoding
Support Main TS stream and the sub TS stream can use different network protocols for transmission (Multi-rate, Multi-resolution, Multi-protocol support)
System supports WINDOWS XP/VISTA/SERVER2003/SERVER2008/WIN7 32 and WIN7 64, LINUX Diversified input interface of Audio & Video.
Support multiple equipments display at the same time on a computer
Providing RTSP/RTP/HTTP/RTMP/UDP/ONVIF protocol
Support up to 6 TS over IP stream out.
Support H.264 Main Profile/H.264 High Profile and AAC audio.
Web control interface
Comply with CBR/VBR 16kbps~40Mbps standard
Power less than 6W, low power watts designing
Support Network interface full-duplex mode 1000M
Specifications
VIDEO SPECIFICATIONS | |
Video | Video compression: H.264/AVC High Profile Level 4.0 Video inputs: Video inputs: HD 1080P(support HDCP protocol) and CVBS Analog video input mode: PAL, NTSC Resolution: Main stream: 1920x1080,1680x1056,1280x720,1024x576,850x480,720x576,720x540,720x480, 720x404,704x576,640x480,640x360,auto Sub-stream: 1280x720,800X450,720x576,720x540,720x480,720x404,704x576,640x480, 640x300,352X288,320X240,320X180 auto Bit-rate: 16kbps ~ 12Mbps, CBR/VBR Video pre-processing: Noise reduction, Sharpen, Filtering |
AUDIO SPECIFICATIONS | |
Audio | Audio compression: AAC, MP3 Sampling rate: Adaptive, output sample rate optional Sampling accuracy: 24-bit Bit Rate: 48000,64000,96000,128000,160000,192000,256000 Re-sample: 32000,44100 |
OUTPUTS | |
IP output | Transport protocol: TS over IP output, HTTP/RTMP/RTSP/HTTP/UDP protocol For HD 1080P to IP output: 4*TS over IP stream out(HTTP/RTSP/UDP or RTMP protocol) 2 Channels with higher resolution(up to 1080P) for large screen application, 2 channels with lower resolution(up to 720P) for small screen application) Connector: RJ45, 100M |
GENERAL OPTIONS | |
System | Protocols: HTTP,UDP,RTSP,RTMP,ONVIF Configuration Interface: Web operation Upgraded: Can be via network for software upgraded. Connector: RJ45, 100M Ethernet interface. |
Physical and power | Voltage: 12V DC Consumption: 5W Operating temperature: 0~50°C Dimensions: 144mm(W)*164mm(D)*38mm(H) Weight: 0.8Kg/pc |
OverView
DMB-8800A Mini HD Encoder features high performance, low latency and low bit rates for IPTV/OTT systems, realized Video & Audio real-time transmission via internet, and adopts state-of-the-art compression technology of H.264/AVC, which realizes its resolution to be up to 1080P. With powerful video pre-compression and efficient adaptive video compression algorithm, it is able to provide clear-delicate, high quality video even at lower bit rate. DMB-8800A can support 1*HD 1080P audio & video capture function, then output dual TS over IP in H.264 format and audio AAC format, can be freely adjusted according to your needs. With high integration, cost-effective, support RTSP/RTP/HTTP/RTMP/UDP protocol, it is very convenient for user, it can work easily just only via plugging the internet cable, thus, avoiding disassemble trouble, no computer hardware compatibility issues, no need the HD capture card configuration, very cost-effective price
MB-8800A can provide the fully functional second development package, which can be applied to education, health care, IPTV, conference, remote education, news interview, court, public security, banking, transportation and other industry application
Applications
Internet TV HD Encoder
Can be accessed NVR for DVR
Digital signage HD stream server
Video conference system video server
Internet conferencing system video capture
Replace HD video capture card
Hotel TV System
High Lights:
1. Support 1 channel HD 1080P+1 channel CVBS input / HD 1080P / SDI/
2. Providing RTSP/HTTP/UDP/RTMP or HLS protocol
3. Support H.264 Main Profile/H.264 High Profile and MP3 & AAC audio compression
