Model: PY600

Name: pressure and temperature indicator

Input signal: MV,DC,DA,R, J, K...

Output signal:  0-10vdc, 0-5vdc, 4-20mA

Application: Pressure, and temperature measurement & controll

Characteristic: temperature indicator, pressure indicator

REF PIC

(1)

Display

Dual 4-digit Green and Red LEDs

(2)

Resolution

0.2% FSO ± 1

(3)

LEDs

Out, Alarm-1, Alarm-2, Calibration

(4)

Input Sensibility

2.5mv/V or 3.3 mV/V (automatic selection)

(5)

Sampling Speed

20 per second

(6)

Excitation Voltage

+9 VDC (output to transducer)

(7)

Temperature Input

Thermocouple “E”, “J”, “K”

(8)

All Output Relays

Relay 220V 1A

(9)

Retransmission

4~~20 mA standard current loop

(10)

Communication

RS-485 MODBUS( MPY602 Only)

(11)

Alarm Range

0001 – 9999 PSI or Bar (configurable)

(12)

Temperature

0 - 55°C

(13)

Humidity

<= 80% RH

(14)

 Calibration

80% FSO (Full Scale Output)

(15)

Power Supply

110/220VAC or +24VDC (designated while purchasing)

(16)

Size

MPY602H: 96mm×46mm×100 mm (W x H x D)

MPY602: 96mm x 96mm x 110 mm (W x H x D)

(17)

Panel Cutout

MPY602H: 96mm x 46mm (W x H)

MPY602: 96mm x 96mm (W x H)

(18)

 Weight

400(Maximum) grams

MODEL FUNCTION OPTION

 Contents

Explanation

MPY500

Pressure controller

MPY600

Pressure and temperature controller

MPY900

Pressure controller with PID

Size

A-

NA

B-

96×96×112(W×H×L)

C-

oblong96×48×112(W×H×L)

D-

 72(W)×72(H)×112(L)

E-

48(W)×48(H)×112(L)

Panel( Annotation 1)

H

oblong Display Digital Display(green)

S

Upright, Display Digital Display(green)

G

upright double digital + double light beams (only for 2-channel meter, 1 channel green, 2 channels red)

Channels

1

1-channel meter

2

2-channel meter

3

NA

4

NA

Input Signals

E

Thermocouple,  Radiation Thermometer

R

Thermoresistance,  resistance

I

DC

V

DV

M

mV DC mV

W

potentiometer

L

Long-Distance Pressure Gauge

 Number of Alarm points

T

T0:  no alarm    T1~T8:  1-8 points alarm

Transforming Output

A0

no Output

A1

Current Output(4~20)mA

A2

Voltage Output(0~5)V,(1~5)V

A3

Voltage Output(0~10)V

A4

other Output

A5

double outputs

 External Power Supply

B0

 no external power supply

B1

 External Power Supply of 24V DC

B2

 External Power Supply of 12V DC

B3

 external power of precise voltage

B4

 external power of precise constant current

B5

 others

 Communication Interface

S0

Communication Interface

S1

RS-232  Interface

S2

RS-485  Interface

S3

RS-422  Interface

S4

BCD  Interface(only for A and B)

 Work voltage

V0

220V AC

V1

24V DC

V2

12V DC

V3

others

 Printing

P

Printing supported,  non essential

 Memory Unit

R

N

 Nonstandard Function

NA
