Metal Geiger Counting Tube Nuclear radiation detection, oil logging, medical and health protection GM TUBE J705 metal case
Metal Geiger Counting Tube Nuclear radiation detection, oil logging, medical and health protection GM TUBE J705 metal case
Metal Geiger Counting Tube Nuclear radiation detection, oil logging, medical and health protection GM TUBE J705 metal case
Metal Geiger Counting Tube Nuclear radiation detection, oil logging, medical and health protection GM TUBE J705 metal case
Metal Geiger Counting Tube Nuclear radiation detection, oil logging, medical and health protection GM TUBE J705 metal case
Metal Geiger Counting Tube Nuclear radiation detection, oil logging, medical and health protection GM TUBE J705 metal case
Metal Geiger Counting Tube Nuclear radiation detection, oil logging, medical and health protection GM TUBE J705 metal case

Metal Geiger Counting Tube Nuclear radiation detection, oil logging, medical and health protection GM TUBE J705 metal case

Share on (60431993361):


Price:RUB 1,114.91 - RUB 2,973.09

Quantity:


Product Overview

Description

  Geiger Muller tube /counter Hard Beta GM Detectors J304

WE SALE DIFFRENT GEIGER TUBE, 100% NEW TUBE, MADE IN CHINA, GOOD QUALITY , PLEASE FEEL FREE TO CONTACT US.

SAMPLE ORDERS ARE WELCOME!

Product Description



  Shenzhen Sunvision Electronics Tech LTD
  ADD: 4th floor 1st Building B Bolck Tangxi the second Industry Area ,Gushu, Xixiang, Baoan District,Shenzhen,China
Tel: +86-755-27918979 cell:86-13480916979
Geiger Muller tube List(glass)
Model no. Size Material Technical parameter working Detecting object
Outer Dim. Total
length		 Recommendation work voltage starting
voltage
maximum		 range of
pleteau
area		 Maximum
Plateau Slope 		Limit working voltage background tenperature Life time
mm mm V V V %/V V Time/minute (℃) (pulse)
J301γβ 10±0.5 205±3 glass 400 ≤350 380-480 0.125 600 50 -40~+70 1*109 γand β
J302γβ 6.2±0.2 65±3 glass 390 ≤350 - - 500 - -40~55 > 150hour γand β
J32γβ 6.5±0.5 34±2 glass 400 ≤350 380-480 0.125 550 5 -20~50 1*109 γand β
J304γβ 10±0.5 90±2 glass 380 ≤350 360-440 0.125 600 25 -40~55 1*109 γand β
J305γβ 10±0.5 107±3 glass 380 ≤350 360-440 0.125 550 25 -40~55 1*109 γand β
J306γβ 18±1 197±3 glass 400 ≤350 360-440 0.125 600 88 -40~55 1*109 γand β
J307γβ 14±1 197±3 glass 400 ≤350 380-480 0.125 600 80 -40~55 1*109 γand β
J308γβ 18±1 143±3 glass 400 ≤350 380-480 0.125 600 50 -40~55 1*109 γand β
M4011 10±0.5 90±2 glass 380 ≤350 360-440 0.125 600 25 -40~55 1*109 γand β



 gm tube all.jpg



Model No. Max Dia. Effective Dia Max Length Effective Length Material Initial Voltage range of pleteau area Mini Plateau Slope Recommendation
operating  voltage		 sensitivity of γ
 (60Co) cps/		 sensitivity of γ
(60Co) cps/ 		Die time background Working temperature range life Detecting
  (mm) (mm) (mm) mm (V) (V) (% /100V)  (V) mR/h) μGy/h) (μs) cpm (℃)
J613γ 9.5 3.5 66 30 glass 350 100 15 420 5 0.5 15 10 -40~+50 1010 γ
J614γ 7.5 3.5 55 30 glass 350 100 15 420 5 0.5 15 10 -40~+50 1010 γ
J401γ 13.5 10 91 50 glass 350 100 15 420 12 1.2 75 10 -40~+50 1010 γ
J622γ 12 5 130 80 glass 350 100 15 420 12 1.2 20 10 -40~+50 109 γ
J403γ 23 18 263 190 glass 350 80 10 420 120 12 150 130 -40~+50 109 γ
J306γ 19 16 200 150 glass 350 80 10 400 80 8 150 80 -40~+50 109 γ
J5101 40 18 180 110 glass 1200 200 5 1400 / / 150   -20~+50 108 γχ
J142αβ 37 16 65 50 metal 450 100 10 550 / /     -40~+60 1010 α β γ
J707γ 6 5 18 6.5 metal 330 100 30 400 2.5 0.25 15   -40~+70 1010 γ
J705βγ 6 5 28 10 metal 400 100 15 500 5.5 0.55     -40~+70 1010 β γ
J301βγ 5 2 45 10 metal 350 100 20 400 0.8 0.08     -40~+70 1010 β γ
J302βγ 6 5 68 36 metal 350 100 15 400 11 1.1     -40~+70 1010 β γ
J303βγ 4 1.2 35 3 metal 350 100 20 400 0.12 0.012     -40~+70 1010 β γ
J304βγ 11 10 95 55 metal 350 100 15 400 37 3.7     -40~+70 1010 β γ
J305βγ 11 10 112 70 metal 350 100 15 400 44 4.4     -40~+70 1010 β γ
J306βγ 17 16 200 140 metal 350 100 15 400 50 5     -40~+70 1010 β γ
J308βγ 19 18 200 140 metal 350 100 10 400 52 5.2     -40~+70 1010 β γ
J4401 23 23 168 120 metal 400 100 10 500 180 18 160 60 -40~+70 1010 γ
J4402 23 23 218 170 metal 400 100 10 500 100 10 160 80 -40~+70 1010 γ
J4403 23 23 268 220 metal 400 100 10 500 115 11.5 160 100 -40~+70 1010 γ
J4405 20 20 168 120 metal 400 100 10 500 75 7.5     -40~+70 1010 γ
J4406 20 20 218 170 metal 400 100 10 500 95 9.5     -40~+70 1010 γ
J4407 20 20 268 220 metal 400 100 10 500 110 11     -40~+70 1010 γ
J502 23 23 180 110 metal 1200 200 5 1400 / /     -20~+50 108 γχ
J503 23 23 80 40 metal 420 100 8 500 / /     -40~+70 1010 α β γχ
J505 15 10 52   metal 420 150 10 500 18 1.8 90   -30~+70 1010 α β γ

 IMG_20140718_150639IMG_20140718_150923J4401-1
