Four Post Mobile Column Truck Lift

Product Overview

Description



                           Qingdao Haolida Automotive Equipment Manufacturing Co., Ltd

A professional manufacture of automotive maintenance and testing equipments for heavy duty vehicles.



                               HLD-QJJ20/30-4C Model  Four Post Mobile Column Truck Lift



Features:

1.Carrying large capacity

2.adjustable runway,easy operation

3.Post orbital mechanical processing a forming, weight evenly, run more smoothly

4.Lifting bracket inside orientation, large loading

5.The planet cycloidal needle wheel deceleration, screw rotation, nut drive tray, Joe fork lift

6.personalized design,reasonable aesthetic

7.Double nuts,Supporting post available ,more safety

8.Four posts can lift together,or single



Technical parameter:

Model	HLD-QJJ20-4C	HLD-QJJ30-4C
lifting capacity	20T	30T
lifting height	1500mm
output speed	50r/min
rising speed	600mm/min
Lifting time	150s
voltage	380V 50Hz 3P
motor power	4*2.2KW	4*3KW



Onsite Using:



Others you may want to know:
MOQ	1set
Warranty period	12 months
Payment term	T/T 50% in advance, the balance be paid before delivery
Delivery time	15 days after receiving downpayment
HS code	8425429000
Packing sizes	Export standard packing



Why Choose us:

1.      32 years’ design,development and produce experience

2.      Professional R&D team

3.      Strict QC

4.      A good pre-sale and after-sale service

5.      Can design and make according to customer’s requests
