Mini industrial 4 10/100M POE Ports 1 100M RJ45 Port POE Switch Total power 120W
- Category: >>>
- Supplier: HiOSO Technology Co. Ltd.
Share on (60433783846):
Product Overview
Description
5 RJ45 Ports with 4 POE Ports 100Mbps Mini POE Switch Manufacturer
Character
(1)Support maximum 4 100M RJ45 PoE ports and 1 100M RJ45 uplink port
(2)Each PoE port supports to auto discovery the standard power receiving devices
(3)Support IEEE802.3af 15.4W and IEEE802.3at 30W PoE standards
(4)Support each 100M port full rate, full-duplex non-blocking forwarding
(5)Support 2K MAC learning, 1Mbit storage and forward cache space
(6)Each RJ45 port using anti-high voltage circuit, strengthen the lightning protection and anti-interference ability
(7)Support to choose one side with fixed metal casing, external power design, better for heat dissipating and installation
Technical Specification
Parameter | Specification |
Standard | IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX Fast Ethernet, IEEE802.3af, IEEE802.3at, IEEE802.1d Spanning Tree |
PoE | PoE ports: 4 Standard and power consumption:IEEE802.3af 15.4W, IEEE802.3at 30W Working mode: auto discovery power receiving devices and auto power supply/power cutting |
Distance | 100m |
Port | 4 100M PoE ports: 10/100Mbps 1 uplink port: RJ45 port 10/100M bps |
MAC | 2K |
Buffer memory space | 1Mbit |
Bit error rate | <1/1000000000 |
MTBF | 100000 hours |
Power | DC48V |
Power consumption | 4W, PoE power supplying maximum 120W |
Working temperature | -10~60℃ |
Storage temperature | -40~80℃ |
Humidity | 5%~90% non-condensing |
Dimension | 26mm (H)×140mm(W)×106mm (D) |
Order information
No | Product code | NMS | Ports | PoE ports |
1 | FOWAY2205P | No | 4 100M PoE+1 100M RJ45 uplink | 4 PoE ports IEEE802.3af 62W |
2 | FOWAY2205P-120W | No | 4 100M PoE +1 100M RJ45 uplink | 4 PoE ports IEEE802.3at 120W |
3 | FOWAY2205PM | Yes | 4 100M PoE +1 100M RJ45 uplink | 4 PoE ports IEEE802.3af 62W |
4 | FOWAY2205PM-120W | Yes | 4 100M PoE +1 100M RJ45 uplink | 4 PoE ports IEEE802.3at 120W |
