Цифровая печать, высокочувствительная CTCP пластина

Product Overview

Description

  New Label Offset Printing, High Sensitive CTCP Plate



New Label Offset Printing, High Sensitive CTCP Plate Technical Specifications
Plate Type	Positive offset plate for UV­-CTP plate making
Application	Medium for sheetfed/web offset press
Substrate	Electro-chemically grained and anodized aluminum
Gauge	0.15 mm, 0.30  mm
Maximum short grain width	0.15 mm: 1050 mm 0.30 mm: 1320 mm
Spectral sensitivity	350-­420 nm UV light 365-­375 nm& 405­-410 UV laser
Safelight	UV filtered or Yellow
Platesetter compatibility	Luscher XPose! UV, Basysprint UV­-Setter, Cron UVP etc.
Sensitivity	50­-60mj/ cm2
Color change	Blue­-Green to Pale Green after exposed
Development	Conductivity: min. 55 ms, max. 70 ms Temperature: 20­-25 °C PH 13.00-­13.40
Developer	Common positive offset plate developer
Dot reproduction	2%­-98% in 200 lines/inch
Final image colour	Blue-­Green
Shelf life	18 months when stored in a light­-free area away from excessive cold, heat and high humidity
Run length	0.30/0.40 mm above 100,000 (Actual run length may vary according to press, ink and stock conditions.)

























































     Sizes of uv-p plate ( ctcp plate ) can be suitable for customers demands.

Huaguang UV-P Positive PS plate is a kind of special high-level high-sensitive plate to meet the

demands of UV-CTP (CTcP)' s development. It fits both UV-CTP (CTcP) platemaking and conventional CTF platemaking. Its unique formulation and technology ensure that it features high sensitivity, strong market compatibility and stable quality. So it is not only suitable for superb color business printing, but also qualified for the requirement of high speed /efficiency for newspaper printing.

















1. If the gross weight of ctcp plate is lower than 50 kgs, you can choose it by Express Courier Service, like DHL, TNT, FEDEX, UPS etc.

2. If the gross weight of ctcp plate is more than 50kgs, you can choose it by Air.

3. If the gross weight of ctcp plate is more than 1000 kgs, you can choose it by Sea.



Precautions:
