12 volt 72w led driver regulated constant voltage led power supply 12v
- Category: >>>
- Supplier: Quanzhou Smarts Electronic & Technology Co. Ltd.
Share on (60434791974):
Product Overview
Description
12 volt 72w led driver regulated constant voltage led power supply 12v
Product Description
| Label |
 |
| Description |
|
Features
- High efficiency,save energy ,protected environment.
- High stability and low ripple, increase light efficiency and decrease light attenuation.
- Meet to safety standard and EMC
- Assure LED stability long lift and light efficiency by constant voltage.
- Integrity protection,over loading, over voltage ,over current.
- 8Hrs and 100% full load burn-in test.
Environment
1.Working Temperature : -25 ~ +50°C
2.Working Humidity : 20 ~ 90% RH non-condensing
3.Storage Temp. , Humidity : -40 ~ +80°C , 10 ~ 95% RH
4.TEMP. Coefficient : ±0.03%/°C (0 ~ 50°C)
5.Vibration : 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
Safety
1.Safety Standards : IEC 61347 –2–11 , IEC 61347 –1 , IEC 60529 , IP67 approved
2.Withstand Voltage : I/P-O/P: 3000KVAC
3.Isolation Resistance : I/P-O/P:100M Ohms/500VDC
Product parameters
Model | Input voltage(AC V) | Working Frequency | Output voltage | Output Current | Output power(DC W) | Working Temp. | Protection grade |
SMT-012-080VW | 100-265V | 47~63HZ | 12 | 6.67A | 80W | -25~50°C | IP67 |
SMT-012-060VW | 100-265V | 47~63HZ | 12 | 5A | 60W | -25~50°C | IP67 |
SMT-024-072VW | 100-265V | 47~63HZ | 24 | 3A | 72W | -25~50°C | IP67 |
SMT-012-072VW | 100-265V | 47~63HZ | 12 | 6.00A | 72W | -25~50°C | IP67 |
Applications
Our products are widely used in various industries, such as
- indoor LED illuminating lights,
- LED Neon,
- LED urban Decoration
- LED Lighting Advertising,
- LED Display,
- Safety Protection Apparatus,
- Telecommunications,
- Networks,
- Vehicle Lights,
- Controller Panels, etc.
Hot Product
Company Information
Company Information
All of our drivers are got ETL CE SAA ROHS listed .OEM Welcome.
Our led drivers are widely used for:
- 1.Indoor LED illuminating lights
- 2.LED Neon, LED urban Decoration
- 3.LED Lighting Advertising,LED Display
- 4.Safety Protection Apparatus
- 5.Telecommunications, Networks
- 6.Vehicle Lights, Controller Panels
Our Market
Our major markets are in EU & North America,it takes about 85% markets share. view transaction history
Certifications
Our Services
Our Services
What Service we can supply??
- 1.All inquiries will be replied within 24 hours
- 2.Professional manufacturer,welcom to visit our website
- 3.OEM/ODM avaliable:
- A.Print logo on our product;
- B. Customized specification;
- 4.After Sales-Service:
- A. All products will have 100% burn-in test and strictly quality test before shipping;
- B. Fast Delivery: 3-7days for samples, 15-20 days for bulk production;
- 5.High efficiency,long life span,reasonable&competetative price,fast lead time;
- 6.We have our engineer team, if you have any question about your LED applications, let us know freely.
FAQ
FAQ
Q1. What's the trade terms you can do??
A1: We accept EXW,FOB..(Optional)
Q2. What's shipping mode can we choose?
A2: Express, Ocean and air transportation (optional).
Q3. What's the MOQ?
A3: Our MOQ is 1pcs. better price for large quantity;
Q4. What can you do if the product is broken?
A4: We promise to replace new ones to you if there is any defective happen during the warranty period.
Q5. Can i get products with my own logo??
A5: Sure, you can, MOQ is 500pcs.
Q6. Can i get a sample for testing??
A6: Sure, but sample fees should be charged on your account.
Q7. What's the mormal lead time??
A7: 7 working days for samples, 15 working days for mass production.
Q8. What's the payment conditon?
A8: T/T in advance or 30% deposit and 70% before delivery (optional)
Q9. What's the Payment do you have?
A9: We accept payment be sent via T/T, L/C, Trade Assurance, WESTERN UNION, PAYPAL.
Q10.How to contact with me??
A9: Skype: steven821228
Whatsapp/Phone: +86 13489577737
E-mail: Sales1 @smartselectronic.com. cn
Send your inquiry details in the bellow for professional reply.
