Huaguang Good Quality Violet CTP Plate,printing plates

Share on (60435471437):


Price:RUB 1,592.18 - RUB 1,895.45

Quantity:


Product Overview

Description

Specifications



+Printing plate manufacturer
+Suitable for newspaper printing
+Negative working
+Violet ctp pate is used on rotary press



 for Digital Printing  Photopolymer Violet CTP Plate



Huaguang PPVS violet CTP plate is specialized for violet ctp platesetter,

which meet newspaper publishing.



+Related Chemicals:



Plates can be developed with Huaguang PPD violet developer and

PPD-R replenisher which are packaged in 20 liters;

Fuji LP-D3WS also can be used.

Protective gum can be Huaguang Gum, or other brand gum.



+Delivering and storing condition:



Recommended delivering conditions should be lower than 28°C and 30-75% RH; If delivering condition is beyond above mentioned limits, the time should not over 24 hours.

Recommended storing condition should be lower than 28°C and 30-75% RH.

After unpacking, the plates should be sealed and packed timely so as to avoid fog caused by humidity

and light when continuous platemaking does not be required.



+Technical Parameters of Huaguang PPVS Violet CTP plate

Type

Violet photopolymer CTP plate

Wavelength

405nm

Sensitivity

70-80uj/cm2

Resolution

150 lpi(3-97%),

10 um micronline output under 1800 dpi

Storage period

12 months, less than 30 °C, dry and lightproof condition

Run length

Without baking

150,000 impression

After baking

500,000impression

Safelight

Amber safelight with brightness between 80-120 LUX, exposing time less than 15 minutes.

Related

chemicals

Developer

Huaguang PPD, Fuji LP-D3WS or Agfa PL-10

Developing Replenisher

Huaguang PPD-R, Fuji LP-D3WS or Agfa PL-10R

Preheating temperature

105-110°C

Developing temperature

25±2°C

Developing time

15-17s

Environment temperature

20-26°C

Environment relative humidity

40-60%
