PRY 6090G Digital Silk Automatic Silk Screen Equipment Machine for Sale

Share on (60439740469):


Price:$10,000.00

Quantity:


Product Overview

Description






Product Description


PRY-6090G Automatic silk screen printing machine





Specifications


1. PRY-6090G One color silk screen printing press printing effect is very excellent by using four air cylinders.


2.The height of screen-release device can be quickly adjusted,ensure printing precision and quality.


3.The tension pressure for printing blade,ink-return blade is adjusted separately at infinite speed,which increases the service lift and printing quality of half tone.


4.Printing stroke and half tone fixed system can be quickly adjusted to meet different printing area.






Main Technical Data:









































































 Model PRY-6090G PRY-8012G
 Max.printing acreage 600×900mm 800×1200mm
 Max.Dimension of the frame 950×1100mm 1250×1500mm
 Dimensions of the workbench 800×1000mm 1000×1300mm
 Printing speed 1200pcs/h 1000pcs/h
 Printing to thickness 0~40mm 0~40mm
 Height of instrant off-network 0-15mm 0-20mm
 Weight(about) 600kg 900kg
 Overall dimensions 1600×1200×1300mm 1900×1400×1400mm
 voltage 3P 380V 50Hz
 Printing motor 0.75KW 1.1KW
 Printing shaft 0.75KW 1.1KW
 Wind machine 1.1KW 1.5KW
 Power 2.6KW 3.7KW








Packaging & Shipping


 transporte picture
