The panel choose high-quality aluminum alloy 5052H32 high-manganese alloy aluminum substrate, sheet thickness1.0~ 1.5mm, core material selected sixangular3003H18 aluminum honeycomb core, aluminum foil thickness: 0.06~ 0.08mm, the total thickness of 10 ~15mm. Panel Material: aluminum, stainless steel plate, the other plate Production: continuous roll forming, single or multi-chip hot pressing at room temperatureadhesive forming three ways
Technical information
Density: 7 ~10kg/m2, Flatness <1mm/m2 Board body thermal resistance 0.026m2.k / w 0.104-0.130W/MK equivalent thermal conductivity, energy absorption capacity of the150-3500KJ / M Sound reduction 29dB Fire rating of EN45545-2 A Elastic modulus of 4 × 104MN/m2 Bending tensile strength ≥ 83MN / m Shear strength 2Mpa Stiffness (kN/m2) 1.0 ~ 23.0 Applicable to the environment: -40 to +80 degrees Celsius the useful life: 2 years warranty
Ordering methods :
(1) on the thickness of the panel (2) under the panel thickness (3) Specifications of the core material (4) plate length, width and total thickness (5) package edge (6) surface coating color
Company Information
Zhangjiagang Jianglian Precision Machinery Co.,Ltd Is located in Suzhou, Jiangsu Province Zhangjiagang Economic Development Zone, convenient transportation, only two hours away from Shanghai Pudong International Airport Founded in 2005,Main aluminum honeycomb core and various types of composite applications sheet.Sold to the Chinese mainland and Taiwan and other regions Load board products for electronics factory instruments, high-precision mechanical platform, chemical fiber rectifier equipment, construction, light construction materialsboard, metro high-speed trains ships and other industrial interiors
