oxygen flowmeter with humidifier bottle/medical oxygen flowmeter

Product Overview

Description

oxygen flowmeter with humidifier bottle/medical oxygen flowmeter

Medical Oxygen Flowmeters With Humidifiers:

·Chrome-plated brass body with all brass high-pressure chamber

·15 LPM Oxygen models provide 115 LPM flood

·Internal reseating relief valve protects against overpressurization

·CE approved

·2″diameter gauge

·Filtered throughout to trap foreign matter and extend regulator life

·Durable neoprene diaphragm

·Polycarbonate inner and outer tubes provide greater accuracy and durability

·Includes plastic swivel hose barb



Gas Type :Oxygen

Input pressure: 15 MPa

Output pressure :0.2-0 .3 MPa

Safety valve: 0.35 + _0.05 MPa

Flow rate :1-15L / min

Inlet Connection: G 5 / 8, CGA540.....

Humidifier capacity:200ML.
