Iron oxide yellow powder

Type                                          Yellow       Pigment
Delivery Form                            Powder pigment
Chemical Class                         Synthetic Iron Oxide
Color Index                               Combination of C.I.77491,77492,77499
Use Recommendation              Coating  Industry

 COLOR VALUES AND TINTING STRENGTH
Reference                                                                                                       Standard: DIN 6174

                                                                        Min                  Max                  Test Method

Reduction with titanium dioxide (1:2)                            R-706                          No.038.2009-08-01

  L*                                                                 -0.7                 +0.7
  a*                                                                 -0.7                 +0.7
  b*                                                                 -0.7                 +0.7

  E*ab                                                                                  1.0

Binder                                                                                 R-05
Relative tinting strength [%]                            95                    105                     No.038.2009-08-01
TECHNICAL DATA

                                                                       Min                Max                     Test Method
Water-Soluble Content [%]                                                1.0                         DIN ISO787 Part 3
Sieve Residue(0.045mm)[%]                                          0.5                       DIN 53195
Fe2O3 [%]                                                      94.0                                         DIN 55913 Sheet 2
Moisture (After Production) [%]                                          1.0                       DIN ISO 787 Part 2

STANDARD PACKAGING           25kg/bag

                                                  Iron oxide yellow 313 pigment

TRANSPORT AND STORAGE
Protect against weathering. Store in a dry place and avoid extreme fluctuations in
temperature. Special conditions for opened packaging: Close bags after use to prevent
the absorption of moisture and contamination.

SAFETY
The product is not classified as dangerous under the relevant EC directives and
corresponding national regulations valid in the individual EU member states. It is not
dangerous according to transport regulations. In countries outside the EU, compliance
with the respective national legislation concerning the classification, packaging, labeling
and transport of dangerous substances must be ensured.
The information contained in the safety data sheet should be observed.
This contains information on handing, product safety and ecology.

This information is given in good faith, without warranty. It is also applies where
proprietary rights of third parties are involved. Our advice does not release you from the obligation to
verify the information currently provided and to test our products as to their suitability for the intended
processes and uses. The application, use and processing of our products and the products manufactured
by you on the basis of our technical advice are beyond our control and, therefore, entirely your own
responsibility. Our products are sold in accordance with the current version of our General conditions of
sale and delivery.
