Tobee Effluent Handling
$12,600
Diesel water pump/3 inches water pump/aircold engine water pump
- Category: >>>
- Supplier: Yancheng Fujiheng Power Machinery Company Limited
Share on (60443635029):
Product Overview
Description
Product Description
| Model | WPD20 | WPD30 | WPD40 |
| Suction,discharge port diameter | 50(1.97) | 80(3.15) | 100(3.94) |
| Discharge capacity(m3/h) | 22 | 30 | 40 |
| Total head lift(m/ft) | 26(85.3) | 25(82.02) | 28(91.86) |
| Max suction head(m/ft) | 8(26.25) | 8(26.25) | 8(26.25) |
| Rotation speed(rpm) | 3600 | 3600 | 3600 |
| Piming time(s/4m) | 80 | 120 | 180 |
| Packing dimension(LXWXH)(mm) | 504X425X540 | 585X470X575 | 670X490X625 |
| Net weight(kg/lbs) | 35(77) | 52(114.4) | 69(151.8) |
| Engine model | JD170F | JD178F | JD186F |
| Ratcd power(KW/hp) | 2.8(3.8) | 4.1(5.5) | 6.3(8.5) |
| Ratcd rotation speed(rpm) | 3600 | 3600 | 3600 |
| Displacement(ml/cu.in) | 211(12.88) | 296(18.06) | 406(24.78) |
| Starting system | Recoil starter/ electric starter | Recoil starter/ electric starter | Recoil starter/ electric starter |
| Fule tank capacity(L/gal) | Smail tank2.5(0.55) | Smail tank3.5(0.77) | Smail tank5.5(1.21) |
| Fuel consumption[g(ml)/kw.h] | 285(339.29) | 283(336.9) | 280(333.3) |
