Certified CE waste tyre rubber processing production line to oil machine

1. No pollution, real enviromental

This is use the coal or wood to heat up the reactor firstly,so we have de-dusting system and waste has combustion chamber. The waste has will buring the furnace and this is the energy saving. And then gas out of chimney will be no smell,no color and odour,it is same as the bule air. Then left the waste gas will be buring at the combustion chamber.

2. High oil yield and quality, no impurities
First,we have the three or four steps impurity the gas.so all the residue will be depositing by this three steps,then after cooling,you will get the high quality oil.

3. High oil yield (3%~5% more oil)
Special new design for cooling system,and we have two vertical condenser and two horizontal condensers,and the important is the oil gas can circulation the condenser,that means cooling distance very long and all the oil gas can circulation in the condenser,some oil gas will be mix the waste gas to burning,so you will get more 3%~5% oil.

4. The best way for change the oil quality
The best way to change the oil quality is control the pyrolysis temperature. If some other suppliers said put the catalyst to change the oil quality,this is fantastic talk. The catalytic the real function is get fast speed of pyrolysis.they can not make sure the oil quality in some way actually.

Machine Parts

Name: REACTOR

Brand: XINDA ENERGY

Original: China

A. Made of Q345R boiler plate
B. Thickness is 16mm
C. Horizontal structure
D. Auto-welded
E. With carbon black auto-discharger inside

Main Features

Name: CATALYST CHAMBER
Brand: XINDA ENERGY
Original: CHINA
A. Made of 10 mm thick steel
B. Vertical structure
C. Auto-welded
D. To speed up pyrolysis

Machine Parts

Name: COOLING TANK
Brand: XINDA ENERGY
Original: CHINA
A. Made of 10mm thick steel
B. Auto welded
C. To store cooling water and use cooling water many times.

Main Features

Name: COOLING CONDENERS
Brand: XINDA ENERGY
Original: CHINA
A. Made of 10 mm thick steel
B. Horizontal structure
C. Auto welded
D. Horizontal condenser has bigger cooling area than vertical condenser and will improve oil output rate dramatically.
