Full Automatic Powder Coating Production Line With Full Spray Pre treament System

Product Overview

Description

XT AUTOMATIC POWDER COATING PLANT



1. BRIEF INTRODUCITON OF XT-AUTOMATIC POWDER COATING LINE



1.1  XT complete powder coating production line design principle:



XT complete powder coating production line is designed on the principle of Advanced technology,

reliable and stable running performace,practial and easy operation, affordable price engergy-saving and environmental protection , and which is fabricated by advanced equipment, experien-

ced processing, and standard fabrication operation to reach the purpose of improving the whole

products coating quliaty on the surface and acheive the top surface coating effect marketing

goals for cusotmers.



1.2  XT complete powder coating production line design basis and requirements:



Meet up with all the regulations and requirements such as local gorverment policy, safety

requirement, workers careen health requirement, fire-fighting requirement, environmental

protection requirement etc.



2. PRE-TREATMENT SYSTEM FOR COMPLETE POWDER COATING LINE



2.1 TECHNICAL REFERENCE





Items	Specification & Descriptions
Selective resolution	Manual pre-treament	Manual polish, mopping, grinding etc
	Mechnical Pre-treatment	Sandblasting, shotblasting etc
	Chemical Pre-treatment	Rust-removal, degreasing, phosphating, passivation etc.
Pretreatment Objective	Remove the dust, rust, grease, dirty substrate on the surface of workpiece and to form one layer density film to improve the adhesive property between spraying coating particles and metal workpiece surface.
Custom Processing Including	Pre-degreasing, Degreasing, Rinsing , Hot water rinsing, DM rinsing ,Surface Conditioning, Phosphating,Oxsilan processing, Compress air blowing etc
Chemical Pretreatment	Dipping Pre-treatment	Workpiece is processed in chemical dipping tanks
	Full Chemical Spray Pretreatment	Go-through type chemical spray pretreatment
Chemical Heating system	By Electricity, Diesel, Gas,LPG or other ways





2.2 CHEMIAL SPRAY PRE-TREATMENT REFERENCE PHOTOS



Chemical Full Spraying Pre-treament system



Chemical Dipping Pre-treament system



3. POWDER SPRAYING & POWDER RECOVERY/ RECLAIM/RECYCLING SYSTEM



3.1 POWDER COATING SPRAY BOOTH



SPRAY BOOTH TYPE    :  Lab-testing use booth, Single position manual spray booth, Double posistion go-through type powder spray booth, Plastic (PVC or PP) powder spray booth;





RAW MATERIAL    : Carbon steel , Glvanizing , Stailess, PVC, PP spray booth are available by us according to your different requirements;



Lab-Tesing Use Powder Spray booth





Single Position Powder Spray booth





Convyoerized double posistion Powder Spray booth







Plastic ( PVC) powder spray booth



3.2 POWDER RECYCLING SYSTEM



Reycling system type :  Custom Cartridge fitlers ,Multi-tubes cylcone & after filter , Mono-cyclone & after filter etc









4. DRYING AND CURING SYSTEM  FOR POWDER COATING LINE



 4.1 TECHNICAL REFERENCE



OVEN TYPES: Batch container type; Go-through straight tunnel oven , Go-through conveyorized Bridge type tunnel oven;

HEATING  FUEL: By Gas, LPG, Diesel, Electric or others fuel;

RAW MATERIAL: Galvanzing sheet,CRS sheet, Rockwool, Profile steel frames etc.

CUSTOM DRYING TMEPERATURE: 100~140℃

CUSTOM CURING TMEPERATURE: 180~200℃

TMEPERATURE TOLERANCE CONTROL: ≤ ±5℃ (Along the conveyor direction)





4.2 REFERENCE PHOTOS







5. CONVEYOR SYSTEM



CONVEYORS TYPE: Overhead hanging conveyor system, Ground rolled conveyor system, manul trolleys system;

TENSIONERS:  Weight tensioners to make sure durablly stable tension property than spring type tensioner;

CONVEYOR LUBRICATING SYSTEM: Oil-spraying cup or oil-dropping cup are available;























5. ELECTRIC CONTROL SYSTEM

PLC control system are available;

MITSUBISHI, SCHNEIDER CNNT, DELIXI  etc Better quality brand are used in our design according to different customers requirement;



6. FACTORY INFORMATION



6.1 COMPANY BASIC INFORMATION:

• More than 15 years' experience in fabricating the complete coating line;
• Fabricating factory invested fund: USD 300,000.00
• Factory occupied Area size: Approximately 18,000.00 squre meters;



6.2 COMPANY MAIN BUSINESS:



FACTORY-A:



• Full Powder coating Production Line
• Complete liquid painting production line
• elctrophoresis production line
• Fokcing production line
• All spare parts and system relating above-mentioned line


FACTORY-B:



• Powder spray gun
• Powder spraying system used high voltage generator

• Flocking equipment

• Relating spare parts such as high voltage cascade, flat nozzle, spray gun shell, etc


If any  complete line or any small spare parts you want to know more ,please kindly contact with me by my contact informations.





7.  REFERENCE PHOTOS:







If anything you want to more, or some spare parts you want to find relating to the line ,please kindly contact with me. i will try my best to offer your free technology surpporting.



I'm waiting for your next earlier inquiry ,visiting factory schedule and order!
