Product Overview

Description

Industrial dust extractor, welding fume/smoke extraction

Features

1. Apply to all kinds of soot purifications caused by welding, grinding, as well as recycling of rare metals, precious

    materials, etc.

2. For the potential of fire and molten slag particles, two protective measures are used inside purifier, to make it a

    longer life, more secure and reliable.

3. For the KSJ-0.7S semi-automatic model purifier, its electric control is simple, automatically cleaning relying on

    the internal pressure sensors, and also can by manual. Filter rotates with the use of semi-automatic cleaning in

    all directions, so that there is a more thorough cleaning filter surface,  to guarantee a constant air volume

    absorption.Filter is made of  imported microporous PTFE film , filtering with high precision can meet GB indoor

   emission standards.

4. Power phase sequence instructions,  short-circuit protection for lack of phase, with shutdown protection

    measures when too high temperature.

5. With large air volume, low noise and better capture effect. Suction hose uses the real anti-temperature, wear-

    resistant compounded materials, without crack and damage to sparks, its life shorter than the model of

    intelligent.

6.Suction arm can be rotated 360 °, and reach the point of destination and angle of inhale dust and air by pulling

   the handle of the hood with the operator’s will flexibly and easily and position by itself in the absence of external

   force. Depending on needs, 2m, 3m or 4m flexible suction arm are optional.

7. Suction arm uses real temperature-resistant, flame retardant and wear-resistant composite materials, and will

    not crack after burning through by spark with longer life; the arm diameter is160mm.

8. 3 years warranty for blowing  fan, the life of filter cartridge is 10000-12000 hours.

Working Principle

Fume generated in working will be sucked into the extractor through the hood, first through the fire resistance net, large particles and sparks produced in grinding is intercepted and separated. Then enter fume directing layer, the deflector to ramify the fume to avoid residual spark into the main filter cartridge directly . At last the fume enters the third layer the main filter cartridge for ultimate purification, and it's filtration efficiency can reach 99.9% . As the filtering precision of the main filter cartridge reach the indoor emission standards, after filtration clean air can be directly discharged indoor through  the air vent in the bottom fo the extractor.

On the control panel, it displays.

--Fan Switch
