miro dc solar pv fuse 24v,high quality fuse link
- Category: >>>
- Supplier: Yueqing Feeo Electric Co. Ltd.
Share on (60447441869):
Product Overview
Description
miro dc solar pv fuse 24v,high quality fuse link
Product Description
MC4 FUSE
1. Solar PV Fuse Holder, DC 1000V,up to 30A fuse.
2. IP67,10*38mm Fusem Copper
3. Suitable connector is MC4 Connector
A range of 10x38mm fuse links specifically designed for protecting photovoltaic strings. These fuse links are capable of interrupting low overcurrents associated with faulted photovoltaic string arrays (reverse current, multi-array fault).
| Product NO. | FMC4FH MC4 FUSE |
| Rated current | 30A(According to the FUSE) |
| Rated voltage | 1000V DC |
| Test voltage | 6000V(50Hz,1min) |
| Overvoltage category/Pollution degree | CATⅢ/2 |
| Contact resistance of plug connectors | 1mΩ |
| Contact material | Copper,Ag plated |
| Insulation material | PPO |
| Degree of protection | IP2*/IP67 |
| Safety class | Ⅱ |
| Insertion force/Withdrawal force | ≤50N/≥50N |
| Connecting System | Crimp connection |
| Temperature range | -40℃~+125℃ |
FAQ
Q: If I'm interested in your MC4 FUSE when I can receive your quotation and detail information after send the enquiry?
A:All your enquiry will be replied in 24hours.
Q:Your MC4 FUSE seems perfect but what's the difference between you and other suppliers?Because I find some cheaper price from others!
A: Our MC4 FUSE are high quality customized.for solar system I think compare the quality first and then compare the price is the best way.
Q:Can I get a sample before the order because I really don't how is your MC4 FUSE quality?
A:Of course!We also think sample order is the best way to build the trust.
Q:How's the delivery?Because I really need them is urgently?
A:For sample order 3~7days will be no problem.And for regular order we promise in 15days.
Q:How's the warranty period for your MC4 FUSE?
A:We offer one year warranty for our customer.
