Features Multi-pole and multi-position Wide variety of actuator and termination options Epoxy sealed terminals prevent contamination during soldering
Specifications:
Contact rating:
CONTACT PLATING
TERMINAL PLATING
RATINGS
Q
Silver
Q=Silver
5 Amps with resistant load @ 120VAC or 28VDC
2 Amps with resistant load @ 250VAC
S
S= silver,pure-tin
C
Gold over Silver
C=Gold over silver
K
K=Gold over silver,pure-tin
R
Gold
R=Gold
0.4 Volt-Amps (VA) max. @20V max. (AC or DC)
G
G=Gold,pure-tin
Materials:
Case: diallyl phthalate (DAP) (ul94V-0)
Actuator: brass and chrome-plated
Bushing: brass and nickel-plated
Housing: stainless steel
Switch supported: brass, tin-plated
Contact/terminals: brass, silver or gold-plated
