Automatic Polishing Sanding Brushing Grinding Mirror Hairline No.4 No.3 Machine for Metal Stainless Steel Aluminium

In order to satisfy the specific Asiatic customers’ request of the surface finishing, especially the general cognizance on Hair-Line(HL), we release JLPTS series: polishing slightly by ScotchBrite™ roller to achieve a similar finishing as Hair-Line(HL). The final surfaces are suitable for mestic appliance, interior design, elevator industry. Therefore, we define this finishing surface as so-call:Easy-Polishing (unidirectional fine polishing by Scotch-Brite™ roller) The JLPTS is characterized by high speed, very easy to use and lower maintenance cost, which can be combined into an existing production line easily.

Model

JMSB1

JMSB2

Number of brushing roller

1

2

Processing type

Dry or wet brushing available for sheets and coils

Useful width

200 - 400 - 700 - 800 - 1050 - 1300 - 1600 - 2100 mm

Min. length

800mm

Thickness range

0.4-3.0mm (standard), maximum 12.0mm (optional)

Feeding speed

8~30m/min (adjustable)

Feeding motor

5.5kW

Main motor

15kW

Brushing roller diameter

φ300mm

Brushing roller speed

700-1400r/min

Dust collection air volume(dry brushing)

4000m³/h

8000m³/h

Filter flow (wet brushing)

250L/min

500L/min

Machine pass line

960mm

Single module weight

7000kg

10000kg
