Biometric Fingerprint Reader time clock Employee Time Tracking Time Recording Machine

Product Overview

Description

Biometric Fingerprint Reader time clock Employee Time Tracking Time Recording Machine

UTOUCH is 7” intelligent access control touch screen terminal with Android/Linux OS comes complete with an SDK and API for general application software integration as access control, attendance, membership and facility management. It is a 5-factor authentication device with optional fingerprint (25,000 templates) + RF Card + Pin code and NFC/BT mobile ID for moible phone access credential. It's with auto focus camera to snap visitor's picture for image records to enhance the security for membership management. It's powered by DC 9-24V, with optional PoE and Battery. With web server, uTouch can build networked central manage system with TCP/IP, 4G, and WiFi enable connection to control centres for ease of management.





Model	CN890 SERIES
Operation System	ANDROID & LINUX
Display	7.0” capacitive touch screen
Smart Card Interface
ISO-protocol	125KHz & Pro, 13.56MHz ISO14443A/B, ISO15693, ISO18092 NFC
Contact smart card	ISO7816 (T=0,T=1) 1 SAM module
Biometric Fingerprint Reader
Fingerprint sensor	500 dpi optical sensor
Template capacity	1:1 (100,000); 1:N (25,000)
General Features
Communication interfaces	4G, WiFI, BT4.0,TCP/IP, RS232, RS485/OSDP, wiegand, USB2.0 (OTG)
Power supply	9-24V DC,Power over Ethernet ,Battery
Camera	Auto focus 5.0 megapixel digital camera
Door phone	Microphone, speaker (controllable volume)
SD card	1 SD card slot
Tamper alarm	1 tamper alarm switch
Operating temperature	0℃~ +50℃
Certification	CE,FCC
