12L R22 R502 R134A R407C R410A Refrigeration Vertical liquid line Receiver Maneurope Liquid Receiver
- Category: >>>
- Supplier: Ningbo Refworld Import And Export Co. Ltd.
Share on (60453913581):
Product Overview
Description
Liquid receivers of a container, it will stored the refrigerant temporary, which is condenser liquefied, before take to expansion valve. When the refrigeration system stop working for a long time and checked, the liquid receivers can take influence on recirling the refrigerant in the system.
| Model | Capacity | Connection(Inch) | Overall Dimension(Inch) | |||
| Compressor(HP) | Volume(L) | Inlet | Outlet | Hight | Diameter | |
| RW-MT010 | 1/2 | 1 | 3/8 | 1/4 | 7.086 | 3.54 |
| RW-MT022 | 1 | 2.2 | 3/8 | 3/8 | 8.267 | 4.72 |
| RW-MT030 | 2 | 3 | 1/2 | 3/8 | 8.267 | 5.91 |
| RW-MT030B | 2 | 3 | 1/2 | 3/8 | 9.84 | 5.196 |
| RW-MT037 | 2 | 3.7 | 1/2 | 3/8 | 13.77 | 4.72 |
| RW-MT040 | 3 | 4 | 1/2 | 1/2 | 10.629 | 5.91 |
| RW-MT50 | 5 | 6 | 1/2 | 1/2 | 11.84 | 6.14 |
| RW-MT060B | 5 | 6 | 1/2 | 1/2 | 9.448 | 7.09 |
| RW-MT080 | 8 | 8 | 1/2 | 1/2 | 11.811 | 7.09 |
| RW-MT100 | 10 | 10 | 5/8 | 5/8 | 11.811 | 8.267 |
| RW-MT120 | 12 | 12 | 3/4 | 5/8 | 13.779 | 8.267 |
| RW-MT140 | 14 | 14 | - | 5/8 | 15.748 | 8.267 |
