1700 c heat treatment furnace for gemstone and ruby heating
- Category: >>>
- Supplier: Zhengzhou Kejia Furnace Co. Ltd.
Share on (60455181791):
Product Overview
Description
1700 c heat treatment furnace for gemstone and ruby heating
Product Description
1700C heat treatment furnace
1. double shell structure and intelligent temp control of phase-shifted control
2. high purity alumina polycrystalline fiber brick for Chamber
3. air cooling system equipped in the furnace shell
4. unique touch screen system bring you convenient operation
Wildly used in universities, research institues, industrial and mining enterprises for high temperature sintering, heating, hardening, oil queching,etc.
Application
Some benefits of the Kejia heat treatment furnace:
no contact between charge and heating spirals
optimal temperature distribution
top insulating materials
low power consumption
high-accuracy programmable temperature control
quick achievement of required temperature
silent operation
top quality and safety standard
Warranty: 24 months
Technical parameter
Take 1700C heat treatment furnace for example:
| Model | KJ-M muffle furnace 1700c |
| Max temp | 1700C (working temp: 1600C) |
| Heating element | MoSi2 |
| Chamber material | Ceramic fiber |
| power supply | 110-450V, 50/60Hz |
| heating rate | 0-20C/min |
| Thermal control acuracy | ±1℃ |
standard size | |
| Chamber size and Effective volum |
|
| 150*150*150mm 3.4L | 300*300*400mm 36L |
| 150*150*200mm 4.5L | 400*400*400mm 64L |
| 200*200*200mm 8L | 500*500*500mm 125L |
200*200*300mm 12L | 600*600*600mm 216L |
| 300*300*300mm 27L | 800*800*800mm 512L |
Note:Customer design size and volume is accepted.
chamber type | side open structure |
Broken accidentally prompt | LCD |
Persisting curve | 15 lines |
control mode | PID |
temperature curve | 30 segments temperature curve can be arbitrarily set |
overtemperature alarm | Yes |
overcurrent protection | Yes |
thermocouple broken prompt | yes |
Electrical certification | CE |
Accessories included | Protective gloves, crucible tongs and a specification |
Our Services
1. Reply your inquiry in 24 working hours.
2. Experienced staffs answer all your questions in fluent English.
3. Customized design is available.
4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.
5. Professional factory : We are manufacturer, specializing in laboratory furnaces.
More information please contact us.
Welcome your inquiry.
