LJZ2 CNC 500*4200A CNC Double head Precision Cutting Saw for Aluminum Profile
- Category: >>>
- Supplier: Jinan Dega Machine Co. Ltd.
Share on (60457496777):
Product Overview
Description
CNC Double-head Precision Cutting Saw for Aluminum Profile
Product Description
Main Function >> DECALUMA
l Computer Integrated cutting saw, Used for Aluminum and Curtain-wall profile accurate and efficient cutting.
l Accurate cutting ensures a high accurate re-load position and convenient man operation work.
l Linear bearing system in moving and feeding device ensures the accurate the machine running and cutting, and stable performance.
l Hydraulic cylinder ensured the stable speed adjusting and saw blade working.
l Cutting length is controlled by computer control system to locate fast and precisely.
l The machine connected with computer, downloaded software to create processing digital, finished CAD/CAPP/CAM.
l Short profile cutting device apply, min. cutting size 150mm and Auto profile supporter available.
l Automatic angle cutting can be changed in 45° and 90°.
l Carbide saw blade for a high quality cutting and life.
l Safety system of shield can ensure the safe operation of man working.
Technical Parameter >> DECALUMA
Power supply | Made to order |
Motor power | 2*2.2KW+3KW |
Motor rotary speed | 3400r/min |
Operation air pressure | 0.5~0.8Mpa |
Air consumption | 200L/min |
Cutting length | 200~4200mm |
Cutting height max | 390mm*90° |
Cutting width | max 190 mm |
Cutting angle | 90°,45° |
Feeding speed | Stepless timing 0~3m/min |
Saw blade specification | φ500mm×4.4mm×φ30mm Z=120 |
Cutting profile surface plane | ≤0.10mm |
Cutting angle tolerance | Ra12.5 μm |
Dimension | 6360mm*1750mm*2100mm |
Weight | 2200kg |
Processing Accuracy >> DECALUMA
Repeat locating ≤0.2mm
Cutting angle allowance ±5'
Cutting profile surface planeness ≤0.10mm
Cutting profile surface roughness Ra12.5µm
Spare Parts Brand >> DECALUMA
Spare parts brand | Brand(source place) |
low voltage electrical parts | Schneider Electric(France) CHINT(Zhejiang ,China) |
Switch button Electrical Parts | Schneider Electric(France) |
Solenoid valve | SXPC(Shanghai,China) |
Cylinder | Air TAC(Taiwan) Huatong(China) |
PU tube | ASHUN (Taiwan) |
Saw blade | WAGEN (Japan ) |
CNC system | Siemens(Germany) |
Guide rail | HIWIN(Taiwan) |
Reducer | Siemens(Germany) |
Motor | MOTOVARIO(Italy) |
IPC | AXIOMTEK(American) |
Bar printer | TSC(Taiwan) |
Servo motor | Yaskawa(Japan) |
Driver | Yaskawa(Japan) |
Integrated software | DECA(China) |
Packaging & Shipping
Packaging and Shipping >> DECALUMA
1.Each product will be carefully packed with plastic film package,to make sure it will arrive safely and available for customized packing.
2.For wooden case, the machine is packed by plastic film first , then packed in wooden case carefully.
Our Services
Our Service >> DECALUMA
1.sample service:
Our engineer is available to travel abroad, help the installation, maintenance and training staff.
2. Customized service:
Free industrial information, free investment analysis for windows, doors, and curtain wall project, free layout design for window, and door and curtain wall product line.
3.After sales service:
One year guarantee
Free adjustment
Free training to operation and maintenance workers
Provide quick supply of spare parts for window and curtain wall companies.
We support Trade Assurance on Alibaba, which is a free payment protection service for buyer regarding product quality and transaction security.
Company Information
Company Profile >> DECALUMA
JINAN DEGA MACHINE CO.,LTD.(decaluma)is located in Jinan city, Shandong province, China, which is a professional exporter and manufacturer focusing on research,production and sale of aluminum profile processing machine.
Our Company is a specialized company that engaged in research,producing and sales of high quality aluminum profile processing machine and windows and door processing machine, we have Export &Import right.
Certificate >> DECALUMA
![{D3UB}IK{6I]J]IOYH11B3V_](http://sc02.alicdn.com/kf/HTB1zhu2untYBeNjy1Xdq6xXyVXal/200400028/HTB1zhu2untYBeNjy1Xdq6xXyVXal.jpg)
Quality Check >> DECALUMA
On the Exhibition >> DECALUMA
Cooperative Partner >> DECALUMA
FAQ
FAQ >> DECALUMA
1 Which equipment does a new door and window factory need?
1).double head cutting saw,model:LJZ2-500*4200A
2).Lock hole copy milling machine,model:LXF-300*100
3).End milling machine,model:LXD-200
4).Automatic Corner connector automatic cutting saw,model:LJJZ-500
5).Single head Corner combining machine,model:LZJ-120C
2. When you can do if my machine have some problems?
1) We can send you free components to you if your machines are in guarantee time.
2) We can send our engineers to repair your machines
3. When can we arrange shipment?
We usually arrange shipment within 15 days after getting deposit,but customized machines should be more than 25 says
4. Are you trading company or manufacturer?
manufacturer(OEM)
Quick details about our company
Company Name | JINAN DEGA MACHINE CO.,LTD |
Year established | 2006 |
Address | No.389,TIANCHEN ROAD,JINAN CITY,250101 CHINA |
Business type | Manufacturer |
Product range | CNC Machining Centre, aluminum cutting machine, corner key cutting, end milling machine,punching machine,copy router, crimping machine, drilling and bending machine |
Product advantage | Using advanced solidworks design platform |
Management certificate | ISO9001,national patent |
Fair we attend | Shanghai and Beijing international windows show |
E-catalog | available |
MOQ | 1 set |
Payment terms | TT or L/C |
Shipping port | Qingdao port |
