Price:RUB 0.7668 - RUB 69.01

Quantity:


Product Overview

Description

 Terminal Blocks

1.Terminal Block - PA Housing & Brass Insert
2.Terminal Block - PA Housing & Steel Insert
3.Terminal Block - PA Hounsg & Steel Insert (Economy Type)
4.Terminal Block - PP Housing & Brass Insert
5.Terminal Block - PP Housing & Steel Insert

 Terminal blocks.jpg



1. Terminal Block - PA Housing & Brass Insert

Characters

  • Polyamide 66, UL 94V-2 flame-retardant housing.
  • Nickel-plated brass contacts with or without steel wire protectors.
  • Recessed screws and tubular contacts provide added safety and help prevent short circuits.
  • 12 poles, can be cut into desired poles.
  • For use in electrical appliances, lighting and building wiring. Especially in OEM & Industry applications.





Model No.ColorWire ProtectorClamping Area / Wire RangeElectrical RatingPacking
PA8HNaturewithout0,75 - 1,5 mm²17.5 A, 450 V, -25°C to T11050 Pcs/Bag
22-12 AWG, Cu20 A, 300 V, 105°C (221°F)500 Pcs/Ctn
PA10HNaturewithout1 - 2,5 mm²24 A, 450 V, -25°C to T11050 Pcs/Bag
22-10 AWG, Sol Cu30 A, 300 V, 105°C (221°F)500 Pcs/Ctn
14-10 AWG, Str Cu
PA12HNaturewithout2,5 - 6 mm²41 A, 500 V, -25°C to T11040 Pcs/Bag
22-10 AWG, Cu35 A, 300 V, 105°C (221°F)400 Pcs/Ctn
PA14HNaturewithout4 - 10 mm² 57 A, 500 V, -25°C to T11025 Pcs/Bag
20-8 AWG, Cu50 A, 300 V, 105°C (221°F)250 Pcs/Ctn
PA16HNaturewithout6 - 16 mm²76 A, 500 V, -25°C to T11010 Pcs/Bag
14-6 AWG, Cu68 A, 300 V, 105°C (221°F)200 Pcs/Ctn
PA18HNaturewithout10 - 25 mm²101 A, 500 V, -25°C to T11010 Pcs/Bag
12-4 AWG, Cu87 A, 300 V, 105°C (221°F)100 Pcs/Ctn
PA8HDSNaturewith0,75 - 1,5 mm²17.5 A, 450 V, -25°C to T11050 Pcs/Bag
22-12 AWG, Cu20 A, 300 V, 105°C (221°F)500 Pcs/Ctn
PA10HDSNaturewith1 - 2,5 mm²24 A, 450 V, -25°C to T11050 Pcs/Bag
22-10 AWG, Sol Cu30 A, 300 V, 105°C (221°F)500 Pcs/Ctn
22-12 AWG, Str Cu
PA12HDSNaturewith2,5 - 6 mm²41 A, 500 V, -25°C to T11040 Pcs/Bag
22-10 AWG, Cu35 A, 300 V, 105°C (221°F)400 Pcs/Ctn
PA14HDSNaturewith4 - 10 mm² 57 A, 500 V, -25°C to T11025 Pcs/Bag
20-8 AWG, Cu50 A, 300 V, 105°C (221°F)250 Pcs/Ctn



2. Terminal Block - PA Housing & Steel Insert

Characters:



  • Polyamide 66, UL 94V-2 flame-retardant housing.
  • Zinc-plated steel contacts provided with or without brass strips.
  • Recessed screws and tubular contacts provide added safety and help prevent short circuits.
  • 12 poles, can be cut into desired poles.
  • For use in electrical appliances, lighting and building wiring. Especially in OEM & Industry applications.



Model No.ColorWire ProtectorClamping Area / Wire RangeElectrical RatingPacking (mm)
PA10RIvorywithout1 - 2,5 mm²24 A, 450 V, -25°C to T11050 Pcs/Bag
500 Pcs/Ctn
PA7Naturewithout0,75 - 1,5 mm²17.5 A, 450 V, -25°C to T11050 Pcs/Bag
22-12 AWG, Cu20 A, 300 V, 105°C (221°F)500 Pcs/Ctn
PA9Naturewithout1 - 2,5 mm² 24 A, 450 V, -25°C to T110 50 Pcs/Bag
22-12 AWG, Cu30 A, 600 V, 105°C (221°F)500 Pcs/Ctn
PA7DSNaturewith0,75 - 1,5 mm²17.5 A, 450 V, -25°C to T11050 Pcs/Bag
22-12 AWG, Cu20 A, 300 V, 105°C (221°F)500 Pcs/Ctn
PA9DSNaturewith1 - 2,5 mm² 24 A, 450 V, -25°C to T110 50 Pcs/Bag
22-12 AWG, Cu30 A, 600 V, 105°C (221°F)500 Pcs/Ctn
PA20DSNaturewith0,5 - 2,5 mm² 24 A, 450 V, -25°C to T11050 Pcs/Bag
22-12 AWG, Sol Cu20 A, 300 V, 105°C (221°F)500 Pcs/Ctn
22-14 AWG, Str Cu
PA30DSNaturewith1 - 4 mm² 32 A, 450 V, -25°C to T11050 Pcs/Bag
22-10 AWG, Sol Cu25 A, 300 V, 105°C (221°F)500 Pcs/Ctn
14-10 AWG, Str Cu



3. Terminal Block - PA Hounsg & Steel Insert (Economy Type)

Characters



  • Terminal Strips
  • Polyamide 66, UL 94V-2 flame-retardant housing.
  • Zinc-plated steel contacts provided with or without brass strips.
  • Recessed screws and tubular contacts provide added safety and help prevent short circuits
  • 12 poles, can be cut into desired poles.
  • For use in electrical appliances, lighting and building wiring. Especially in DIY & Installation applications.



Model No.Colorw/without Brass StripClamping Area / Wire RangeElectrical RatingPacking
PA10RIvorywithout1 - 2,5 mm²24 A, 450 V, -25°C to T11050 Pcs/Bag
     500 Pcs/Ctn
PA20Naturewithout0,5 - 2,5 mm²24 A, 450 V, -25°C to T11050 Pcs/Bag
   22-12 AWG, Cu20 A, 300 V, 105°C (221°F)500 Pcs/Ctn
PA21Naturewith0,5 - 2,5 mm²24 A, 450 V, -25°C to T11050 Pcs/Bag
   22-12 AWG, Cu20 A, 300 V, 105°C (221°F)500 Pcs/Ctn
PA30Naturewithout1 - 4 mm²32 A, 450 V, -25°C to T11050 Pcs/Bag
   22-10 AWG, Sol Cu25 A, 300 V, 105°C (221°F)500 Pcs/Ctn
   14-10 AWG, Str Cu
PA31Naturewith1 - 4 mm²32 A, 450 V, -25°C to T11050 Pcs/Bag
   22-10 AWG, Sol Cu25 A, 300 V, 105°C (221°F)500 Pcs/Ctn
   14-10 AWG, Str Cu
PA40Naturewithout2,5 - 10 mm²57 A, 500 V, -25°C to T11040 Pcs/Bag
   18-10 AWG, Sol Cu30 A, 300 V, 105°C (221°F)400 Pcs/Ctn
   16-10 AWG, Str Cu
PA41Naturewith2,5 - 10 mm²57 A, 500 V, -25°C to T11040 Pcs/Bag
18-10 AWG, Sol Cu30 A, 300 V, 105°C (221°F)400 Pcs/Ctn
16-10 AWG, Str Cu





4. Terminal Block - PP Housing & Brass Insert



 Characters



  • Polypropylene, UL 94V-2 flame-retardant housing.
  • Nickel-plated brass contacts.
  • Recessed screws and tubular contacts provide added safety and help prevent short circuits.
  • 12 poles, can be cut into desired poles.
  • For use in electrical appliances, lighting and building wiring. Especially in DIY & Installation applications.





Model No.ColorWire ProtectorClamping Area / Wire RangeElectrical Rating (mm)Packing
PA8PWhitewithout0,75 - 1,5 mm² 17.5 A, 450 V, -20°C to T8550 Pcs/Bag
22-12 AWG, Cu20 A, 300 V, 85°C (185°F)500 Pcs/Ctn
PA10PWhitewithout1 - 2,5 mm²24 A, 450 V, -20°C to T11050 Pcs/Bag
22-10 AWG, Sol Cu30 A, 300 V, 85°C (185°F)500 Pcs/Ctn
14-10 AWG, Str Cu
PA12PWhitewithout2,5 - 6 mm²41 A, 500 V, -20°C to T8540 Pcs/Bag
400 Pcs/Ctn
PA14PWhitewithout4 - 10 mm²57 A, 500 V, -20°C to T8525 Pcs/Bag
250 Pcs/Ctn
PA16PWhitewithout6 - 16 mm²76 A, 500 V, -20°C to T8510 Pcs/Bag
200 Pcs/Ctn
PA18PWhitewithout10 - 25 mm²101 A, 500 V, -20°C to T8510 Pcs/Bag
100 Pcs/Ctn



5. Terminal Block - PP Housing & Steel Insert

Characters

  • Terminal Strips
  • Polypropylene, UL 94V-2 flame-retardant housing.
  • Zinc-plated steel contacts.
  • Recessed screws and tubular contacts provide added safety and help prevent short circuits.
  • Easy cutting design.
  • Save more cost with no compromise on quality.
  • For use in electrical appliances, lighting and building wiring. Especially in DIY & Installation applications.
Model No.ColorContactsClamping Area/Wire RangeElectrical RatingPacking
PA20PWhitesteel0,5 - 4 mm² 32 A, 450 V, T8550 Pcs/Bag
22-12 AWG, Cu20 A, 300 V, 65°C (149°F)500 Pcs/Ctn
PA30PWhitesteel1 - 6 mm² 41 A, 450 V, T8550 Pcs/Bag
22-10 AWG, Sol Cu25 A, 300 V, 65°C (149°F)500 Pcs/Ctn
14-10 AWG, Str Cu
PA40PWhitesteel2,5 - 10 mm² 57 A, 500 V, T8540 Pcs/Bag
18-10 AWG, Sol Cu30 A, 300 V, 65°C (149°F)400 Pcs/Ctn
16-10 AWG, Str Cu
PA50PWhitesteel4 - 16 mm²76 A, 500 V, T8525 Pcs/Bag
250 Pcs/Ctn
PA60PWhitesteel10 - 25 mm²101 A, 750 V, T8510 Pcs/Bag
100 Pcs/Ctn
