agricultural mini rotary tiller made in China with great price

Product Overview

Description

agricultural mini rotary tiller made in China with great price

Rotary Tiller is driven by the tractor's out-put shaft. During operation, the soil is crumbled by the rotating and forwarding of the blades fixed on the shaft. It also can be used as shallow tilling and covering on the Stalinized soil to prevent the salt in the soil. The machine will fulfill the working of cleaning stubbles and weeds, turning and covering green fertilizer and preparing vegetable fields, etc.



After tillage, the land surface is leveling and smooth, the cover burden is closely, working efficiency is high and oil consumption is lower.



Main Specifications:



Model	1G-120	1GN-125	1GN-140	1GN-150	1GN-160	1GQN180	1GQN200
Working Width   (cm)	120	125	140	150	160	180	200
Working Depth  (cm)	Dry land  8~14,Paddy field 14~16					Dry land   8~16,Paddy field  10~18
Type of Blade	IT225					IT245
Nos of Blade (per)	24	24	30	34	38	50	58
Overall Dimensions (L×W×H) (cm)	90×154×109	90×136×109	90×169×109	90×170×109	90×188×109	102×210×115	102×235×115
Total Weight   (kg)	170	182	214	240	260	405	420
Rotary Speed of Tractors' PTO (rpm)	540					540/720
Rotary Speed of Blade Axle (rpm)	199	213				200(Tractors' PTO is 540rpms),197(Tractors' PTO is 720rpms)
Working Speed   (km/h)	1  ~  3					2  ~  5
Productivity  (ha/h)	0.3-0.47	0.3-0.47	0.33-0.0.5	0.36-0.56	0.38-0.62	0.53-0.74	0.6-0.8
Hitch Type	three-point mounted
Matched Power (kw)	13.2-18.4	13.2~18.4	18.4~22	22~29.4	29.4~36.7	36.7~40.4	40.4~55
