Manufacturer High Quality CNC Helical Rack for CNC Flame Plasma Cutting Machine

Product Overview

Description



1)Quick Detail:
1. CNC Guide Rail and Rack for Gantry Cutting Machine
2. Longteng brand
3. CNC Rail Type: 24kg ,38kg , 43kg, 50kg.

4. Achieve the gantry cnc machine for the stable moving and the high precision

2)Structural Features:
1. Surface treatment : Smooth and Beauty
2. The length up to constumer's need.
3. It is used for CNC Gantry Cutting Machine
4. 100% inspection on critical dimension with high accuracy ±0.01-0.005



3) Details for rail, rack ,pinion ,clip and bolts.

1. About Rail , we have four type: 24KG, 38KG, 43KG and 50KG .

2. About Rack and Helical Rack Dimension has the following size:

 (1) 20mm*20mm*999mm ; module: 1.5 or 2 ( decided by customers' requirment)

 (2) 25mm*25mm*999mm ; module: 1.5 or 2  (decided by customers' requirment)

 (3) 20mm*40mm*999mm ; module: 1.5 or 2  (decided by customers' requirment)

 pls note: per 2 meters rail will need 2pcs rack.

       note: helical rack MOQ ≥50 pcs

3. About Pinion : we usually make according to customers' drawing or requirment.

4. About Rail Accessories : it is used to fix the rail, including rail clip and bolts

pls note: per 2 meter rail will need 3 pcs rail accessories.



The rail is the part which use for the cnc gantry cutting machine which include the H Type support rail beam.

big and small base plate , left and right adjustment bolt , the first nut , pressing plat bolt, high and low bolt. the mentioned big and small base plate welding on the H beam support rail beam for support the rail; the big and samll base plant has the left and right adjustment bolt and first nut to adjust the left and right position of the rail; the mentioned big and small base plant has the fixed bolt which could compress the rail , the rail has the high and low adjustment bolt to adjust the high and low position of that.



Above that all , the connection place insert the tie rod , use bolt , the second nut and joint ring for fixing ,which could achieve the gantry cnc machine for the stable moving and the high precision.

4) Specifications of rail:

Model	Length1	Length2	Top Width	Base Width	Height
24KG	2 meter	3 Meter	45mm	92mm	103mm
38KG	2 meter	3 meter	55mm	108mm	120mm
43KG	2 meter	3 meter	55mm	108mm	133mm
50KG	2 meter	3 meter	55mm	125mm	142mm





5) Maintenance Skills:

1. Replace the consumbles in time before completely damaged.

2. Avoid the collision of the torch height controller

3. Keep the connection threads clean

4. Check if there are loose parts
