Brand New 18 20 Seater Ankai Electric Mini Bus Price
- Category: City Bus >>>
- Supplier: JC Automobile Co. Limited (Shanghai)
Share on (60459715417):
Product Overview
Description
Brand New 18 - 20 Seater Ankai Electric Mini Bus Price
Product Description
| Vehicle model No | HFF6660GEVB | |
| Overall configurations | overall dimension(mm) | 6620X2280X2920/3120 |
| approaching angle/departure angle(º) | 18/11 | |
| wheelbase(mm) | 3308 | |
| front/rear suspension(mm) | 1180/2132 | |
| Seat capacity | 18+1 | |
| Kerb weight(kg) | 5520/5710 | |
| Max weight(kg) | 8000 | |
| Max Speed(km/h) | 69 | |
| Chassis configurations | Lithium battery manufacturer | Guoxuan |
| Lithium battery model No | 86AH/512V | |
| Driving motor manufacturer | JEE Automation Equipment Co., Ltd. | |
| Drive motor model No | JEETZ260XS1240 | |
| Motor controller manufacturer | JEE Automation Equipment Co., Ltd. | |
| Motor controller model No | JEETK53X60S01 | |
| Vehicle control manufacturer | Anhui Jianghuai Automobile Co., Ltd | |
| Vehicle controller model No | AKEVCU-1 | |
| Suspension system | leaf spring | |
| Front axle | JAC 3.0T/drum brake | |
| Rear axle | Hefei AAM 5.0T/drum brake | |
| service brake | Dual-circuit air brake, automatic slack adjuster | |
| Parking brake | Spring energy storage brake | |
| ABS | ABS(Made in China) | |
| Steering system | Chinese hydraulic power | |
| Tire | 7.50R16(Chinese)/6pcs, with wheel cover | |
| Body configurations | Frame | monocoque |
| Air conditioner | Electric heating and cooling air conditioner, 12000kcal/h | |
| Fuel heater | No | |
| Heater radiator | No | |
| Defroster | Standard | |
| Floor leather | Made in China | |
| Interior lighting | Through-type lamp | |
| Driver seat | Made in China | |
| Passenger seat | 18 injection molding passenger seats | |
| Reversing Mirror | Rabbit-style mirror | |
| dashboard | Made in China | |
| Painting | Chinese brand, solid painting | |
| Safety sunroof | Safety roof with ventilator/1 piece | |
| Passenger door | Middle / rear door, pneumatic folding door | |
| Front glass | Fron laminated glass with sunshade | |
| Side window glass | Side window toughened glass, folding curtain | |
| Others | 4 kg of fire extinguisher, power steering pump, electric pump | |
