High accuracy medium preload HGW25HB CNC linear guide rail

Product Overview

Description

Linear guide rail HGW25HB Description

• HIWIN HGW series linear guideway is heavy load linear guideway designed by circular-arc groove and structure optimization are higher over 30% load capacity and rigidity than other similar ball type linear guideway.


• It features the same load in four directions (up/down/right/left) and self-aligning to absorb installation-error capability.


• HG series linear guideway can achieve a long life with high speed, highly accurate and smooth linear motion.


• HGW25HB is super heavy load with flange blocks,the block mounting is top of bottom.


• Linear slide rail as a type of rolling guide, run by the power between infinite scroll circulation steel ball in the slider and slippery course, along the slippery course load platform can easily do high precision linear movement.


• Compared with the traditional sliding guide, rolling guided friction coefficient can drop to as low as 1/50 of the original, greatly decrease relatively less invalid movement, therefore, it can easily achieve μ m class feed and positioning. Plus bound unit design between the slider and slippery course, making the linear slide rail withstand the load from up and down and other directions, above displayed characteristics traditional sliding guide can't match, then if the machine can cooperate with ball screw, use linear slide rail for guidance, will greatly improve the accuracy and efficiency of the mechanical equipment.

Feature of Linear guide rail

• Easy lubrication


• Interchangeability


• Self-aligning capability


• High rigidity,highly accurate


• Heavy load radial linear guides


• Smooth runningHigh speed and accuracy


• Low friction & vibration


• Low noise and non-pollution


• Achieve a long life with high speed


• The accuracy of HGW series can be classified into normal(C),high percision (P),super precision(SP),ultra precision(UP),five lasses,please choose the class by referring the accuracy of applied equipmet


• HIWIN HGW Series is a preload can be applied to each guideway,oversized balls are used.Generally,a linear motion guide rail has a negative clearance between groove and balls in order to improve stiffness and maintain by the preload,the rigidity is doubled and the deflection is preload,the rigidty is doubled and the deflection is reduced by one half,the preload not larger than ZA would be recommernded for the model sze under QH20 to avoid an over preload affecting th liear guide rails life

Application of Linear guide rail

• XY-table


• Lathe machine


• Marble cutting machines


• Heavy cutting machines


• Machine centers,Machine tools


• Precision machining machines


• Heavy cutting machines,Punching machines,


• Automatic equipments,Grinding machines


• High speed transfer equipments


• Injection molding machines


• Measuring equipments.

Linear guide rail Details:
Name	linear guide rail, slide block, linear motion,
	linear guideway, linear module, linear actuator
Brand	ABBA, HIWIN, THK, PMI, IKO,TBI,NJSKT
modele	HGW25HB
rail lenght	100mm/-4000mm lenght can provide
size:	following list
Minimum quantity:	1 piece slide block and 100mm linear rail
Precision:	N, H, P, SP, UP
Pre-pressing	ZF, Z0, Z1, Z2, Z3
Lubrication:	grease
Seal Types	open or sealed
Material:	steel
packing	the original color box packaging

Linear guide rail HGW25HB available designs





Linear guide rail picture show







Linear guide rail Warehouse to show >>>>>
