pid temperature controller

  intelligient portable small size 48*24mm XMT-7100 universal input pid temperature controller pt100

Product Descriptions:

  intelligient portable small size 48*24mm XMT-7100 universal input pid temperature controller pt100

1.  digital pid temperature controller Product Highlights

Thermocouple: T, R, J, B, S, K, E, Wre3-Wre25.

Thermo Resistor: Pt100, Cu50.

1 Relay output, 1 SSR controlled output.

Time proportional PID controlled output to either Relay or SSR

Three built-in algorithms that fit most control objects and various applications.

Temperature can be set to display in either Fahrenheit or Celsius degrees.

2.  digital pid temperature controller Specifications

Supply voltage: 12V AC or DC

Power consumption: < 2 Watts.

Sampling speed: 4/sec.

SSR activated voltage: open circuit: 10V; short circuit: 40mA.

Accuracy: 0.2% of full scale.

LED Display: Red, 0.28 inch

Out of range indication: “EEEE”.

Ambient temperature requirements: 0 to 50 C (32 to 122 F)

Humidity requirement: < 85% RH.

Relay Contact: 220VAC, 3A.

Controller dimensions: 48 x 24 x 75 (mm).

Opening for installation: 44 x 20 (mm)

Our company's name is Shanghai Te Shi Machinery Co., Ltd. special when we are just beginning to trade the new company.
We have a lot of experience of export products.
1. We have 10 technical staff  professional design R & D engineers, we probably have five foreign trade personnel.
2. We have our own factory, we have two factories responsible for producing temperature controller and sensors.
3. We plant employees about 200,
4. Our company was established about a year, our main markets in the United States, Europe and so on.
5. Our company is divided into two parts one is responsible for sales in Shanghai, one of the main responsible for the production of Jiangsu Province in China.
6. our customer service 24 hours online for your service, you no matter what problems we will in the shortest possible time within

Shanghai Te Shi Machinery Co., Ltd.
 is one of the areas of high-tech enterprises, with Shanghai and many other research institutes and universities jointly developed a series of temperature-controlled production of electronic products sold throughout the country. Products are renowned for their excellent performance, good looks, reliability, advanced technology, good price and market reputation, won the trust of users. 2000 has passed ISO9001: 2000 quality system certification, the company has first-class production lines and testing instruments, the quality of supervision of the whole process. Enterprises have a strong technical development team and the outcome of the patent, willing to undertake regular and special products business. For the design, installation of a variety of large, medium and small automatic temperature control system. Enterprise has always believed in the "quality of legislation market, users struggle credibility, technology and development" purposes. Welcome new and old customers to buy! Thermocouple developed under special conditions: the temperature of the thermocouple as a solution in steel, copper water, aluminum water, zinc, water, and salt and other melting furnaces, cement factories and power plants, and thermocouple under special environments, high-precision long service life, the new oxidation tungsten rhenium thermocouples, low cost, high temperature, is the ideal alternative to platinum and rhodium thermocouple, some products reach the level of military products. Produced by polytetrafluoroethylene (PTFE) tubes, plates, rods, gaskets, shaped pieces and other products, resistant to acid, alkali, corrosion resistance, ideal for a wide range of high temperature, environmental protection, use, the company has a strong technology development and patent portfolio results, to undertake regular and special products business, customers can design, installation of various large and small automatic temperature control and remote monitoring body temperature control system.
