Place of Origin | China |
Jiangxi | |
Brand Name | YIBO |
Video outgoing-inspection | Provided |
Machinery Test Report | Provided |
Marketing Type | factory directly sale |
Warranty of core components | 1 Year |
Core Components | PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump |
CNC or Not | CNC |
Weight (KG) | 6000 |
Condition | New |
Material | Other, Aluminum, Copper |
Coil Type | Round, Oval, rectangle |
Key Selling Points | Flexible Manufacturing |
Applicable Industries | Manufacturing Plant |
Warranty | 1 Year |
Field maintenance and repair service, Field installation, commissioning and training, Video technical support, Online support, Free spare parts | |
After Warranty Service | Video technical support, Online support, Spare parts, Field maintenance and repair service |
Model | BRL-800 |
Coil outer diameter | 200~600mm |
Foil band width | 300~1600mm |
Line material shape | Circular,Square,Rectangle |
Conduxtive foil material | ALu foil or copper foil |
Thickness of conduxtive material | Alu0.5~2mm,copper0.5~1.6mm |
Layer-insulation amount | 1~2 |
Winding speed | 0~35r/min(Pedal unrolling control,stepless adjustment) |
Soldering speed | 0~0.7m/min(Mcanual,Automatic,Pneumatic control,Stepless adjustment) |
Max tension of foil band | 20000N |
