New design post hole digger machines

Product Overview

Description

New design post hole digger machines

 The digger  series are simple to operate ,safe and reliable,efficient,and easy to maintenance.They are suitable for the different situations,such as sand,hard land,etc.They are the ideal machines for afforestation.They match  20-80 hp tractors.



Specifications for digger:

Model	1WX-230	1WX-300	1WX-400	1WX-500	1WX-600	1WX-700	1WX-800	1WX-1000
Overall Dimensions (L×W×H) (cm)	230×80×165		230×80×165				240×80×165	245×100×165
Drill diameter (mm)	230	300	400	500	600	700	800	1000
Working depth (cm)	40-70			50-80			50-100
Matched Power (kw)	14.7-29.4		22-53		36.7-55
Weight (kg)	150	165	230	240	251	260	270	300
PTO Speed (rpm)	540		2.18:1(when PTO speed is 540rpms),                            3:1(when PTO speed is 720 or 760rpms).
Gearbox rate	2.92:1
Linkage	3-point lift with no tractor suspension
Efficiency (caves/hour)	60-150	60-120				30-60
Transport clearance	>30cm
