Optical Colposcope / Gynecology Equipment Colposcope/ Video Colposcope

Product Overview

Description



 Optical Colposcope Microscope

JM II Colposcope:

Observation angle: 45°tilted

Magnification of eyepiece: 16X

Interpupillary distance: 50mm-80mm

Diopter: ±5D

Focal length of objective: F=300mm

Magnification changer: 5-step: 0.4X, 0.66X, 1X, 1.5X, 2.5X

Total Magnification: 2.7X, 4.4X, 6.6X, 10X, 16.6X

Linear field: 90mm, 55mm, 37mm, 24mm, 15mm

Fine focusing distance: 20mm

Balance arm: Counterweight adjustable and can be locked

Illumination: Coaxial illumination with cold light source fiber-optic cable, 21V150W halogen lamp, brightness adjustable

Illumination: >15000lux

Filter: Build-in green & blue filter

Stand: Short column fitted on the five-star base

With beamsplitter, and TV adapter, C-mount 1/3" CCD camera attachable

Optical Colposcope Microscope Power supply: AC110V60HZ/AC220V50HZ

Optional accessories: Demonstrator, Camera (), Photo adapter, Monitor H1766, Objective (F=230mm & F=280mm)

 Optical Colposcope

Optical Colposcope Microscope



Optical Colposcope Microscope

JM II-L Colposcope:

Observation angle: 45°tilted

Magnification of eyepiece: 16X

Interpupillary distance: 50mm-80mm

Diopter: ±5D

Focal length of objective: F=300mm

Magnification changer: 5-step: 0.4X, 0.66X, 1X, 1.5X, 2.5X

Total Magnification: 2.7X, 4.4X, 6.6X, 10X, 16.6X

Linear field: 90mm, 55mm, 37mm, 24mm, 15mm

Fine focusing distance: 20mm

Balance arm: Counterweight adjustable and can be locked

Illumination: Coaxial illumination with 10W LED light source, brightness adjustable

Illumination: >20000lux

Filter: Build-in green & blue filter

Stand: Short column fitted on the five-star base

With beamsplitter, and TV adapter, C-mount 1/3" CCD camera attachable

Power supply: AC100V-240V

Optional accessories: Demonstrator, Camera , Photo adapter, Monitor H1766, Objective (F=230mm & F=280mm)



Optical Colposcope Microscope

JM II-1L Colposcope:

Observation angle: 45°tilted

Magnification of eyepiece: 16X

Interpupillary distance: 50mm-80mm

Diopter: ±5D

Focal length of objective: F=300mm

Magnification changer: 5-step: 0.4X, 0.66X, 1X, 1.5X, 2.5X

Total Magnification: 2.7X, 4.4X, 6.6X, 10X, 16.6X

Linear field: 90mm, 55mm, 37mm, 24mm, 15mm

Fine focusing distance: 60mm

Illumination: Coaxial illumination with 10W LED light source, brightness adjustable

Illumination: >20000lux

Filter: Build-in green & blue filter

Stand: Column height adjustable fitted on the round base with 5 jaws

With beamsplitter, and TV adapter, C-mount 1/3" CCD camera attachable

Power supply: AC100V-240V

Optional accessories: Demonstrator, Camera , Photo adapter, Monitor H1766, Objective (F=230mm & F=280mm)
