Equipment plant for gypsum board machine price,gypsum board making machine
Technique adopts the German GRENZEBACH BSH and GYPTECH company, Lafarge,
the United States INC companies and domestic wellknown enterprises Kitashinchi Group,
Taihe Group advanced technology. We adopts the horizontal flow, vertical airflow heat exchanger
heating system, the raw material feeding system and edge cutting and edge sealing and edge grinding and recycling system and stacking system are all controlled by computer. All the whole line is full automation.
Annual capacity(m2) | Day capacity(sheet) 1200*2400*9mm |
Drier layer |
Heating system | Control system | Fuel |
2 Million | 2000 | 4 |
Heat ex-changer (vertical Air-blow) | PLC |
Coal, gas, oil .etc |
3-4Million | 3000-4000 | 6 | PLC | ||
5-8Million | 5000-8000 | 8 |
DCS computer control | ||
10-15Million | 10000-15000 | 10 | |||
20-50Million |
20000-50000 | 12 | Heat ex-changer(Horizontal Air-blow) |
production capacity | 2 to 50million square meter per year |
Finished product | paper-faced gypsum board/ fire resistance gypsum board water resistance paper-faced gypsum board |
specification | thickness from 6.5-16mm length from 2100-3600mm width from 1220mm |
Quality standard | over the international standard GB9775-1999 |
Property | full automatic |
fuel variety | oil,coal,gas .etc |
automatic equipment of gypsum board
1: Production machinery part and Raw material distribution: hoist, storage, measuring scale,
Dynamic foaming station, powder conveyor (inverter), pulp conveyer (inverter), pulp stirring pot,
vertical mixer. The function of this part is to lift the powder to the vertical mixer through hoist,
conveyor and measuring equipment, and then proportionally mix and stir with the powder pulp
and frothing preparation coming from pulp pump and measuring equipment, and thus gypsum
thick liquid of a certain thickness is produced.
2: Heat transmission stove system of paper faced gypsum board production
Main equipments: stove body, heavy oil burner, circulating pump, high and low oil storage,
oil pipe, low and high pressure oil pipe and electric controlling part. The function of this system
is to supply heat for drying system. he burning material can be decided according to the local energy resources situation,
such as coal, diesel and natural gas.
3:automatic machine of gypsum board Production line automatic controlling system.
It includes two parts:
PLC and computer monitor system & Computer controlling part
