Product Description

  High speed sausage linking machine, sausage twister machine,

sausage tying machine

 This machine used on twisting and clipping sausages by string or wire, after filling by sausage filler,

the whole sausage is one complete long one, so we should clipping it to many segments by clipper,

 it is semi automatic work, pneumatic driving by air compressor, made of all stainless steel, fast

twisting and kinking sausages, clipping sausage to many pieces with different lehgths, the length of

each part sausage is adjustable and controlled by need, we could control the length by ourselves.

sausage tying machine1.jpg

Machine Features

1. Stepless adjustable length for filling. Accurate and Even.

2. Just by drawing the thread, the sausages needn't to be cut when packing.

3. Labour saving and no contamination.

4. Reliable performance, low maintaining cost.

Technician Parameter



Model

RYZX-1

RYZX-2

Air pressure

0.4-0.6Mpa

0.4-0.6Mpa

Capacity

40-60pcs/minute

60-180pcs/minute

Casing range

Diameter 10-35mm

Diameter 10-35mm

Dimension

1150*480*750mm

1670*720*950mm

Single section intestinal body length

30-135mm

30-135mm

Detailed Images

 sausage tying machine2.jpgsausage tying machine3.jpgsausage tying machine4.jpgsausage tying machine5.jpg
