Hydraulic electric aluminum telescopic antenna mast one man lift
Hydraulic electric aluminum telescopic antenna mast one man lift
Hydraulic electric aluminum telescopic antenna mast one man lift
Hydraulic electric aluminum telescopic antenna mast one man lift
Hydraulic electric aluminum telescopic antenna mast one man lift
Hydraulic electric aluminum telescopic antenna mast one man lift
Hydraulic electric aluminum telescopic antenna mast one man lift

Hydraulic electric aluminum telescopic antenna mast one man lift

Share on (60470711213):


Price:

Quantity:


Product Overview

Description


Product Description
Product Introduction

Hydraulic electric aluminum telescopic antenna mast one man lift adopts high strength aluminum alloy, light weight, compact main body, easily pushed around to the designated sites. Its regular platform height is 4m, 6m, 8m, 10m etc, the max height can reach 20m. Its rated capacity is from 100KG to 250KG.

Main Features

1)High strength aluminum alloy, light weight and samll volume, easily pass through narrow space

2)Safety:

a. Explosion-proof valve: it will prevent upper platform from dropping suddenly when power cut off or oil tube burst.

b.Emergency lower valve: It can go down by manual control when power off suddenly or any other emergency.

c.Spillover valve: adjust work pressure when aluminum alloy lift platform goes work.

d.Safety guardrail

3)Control device:

a. Push button box, which may be placed on the platform for the convenience of operation.

b.Switch box, with emergency stop button for prevention of any accident.
c. Manual lowering valve
4)Power:AC power or DC power. which is optional as per customer's actual needs.
\t
Model
\t
Platform height

\t
Work height
\t
Rated capacity
\t
Platform size
\t
Power
\t
Weight
\t
      Overall size
\t
SJYL-4
\t
4m
\t
5.7m
\t
125kg
\t
600x550mm
\t
0.75kw
\t
220kg
\t
1300x800x1620mm
\t
SJYL-6
\t
6m
\t
7.7m
\t
125kg
\t
600x550mm
\t
0.75kw
\t
270kg
\t
1300x800x1620mm
\t
SJYL-8
\t
8m
\t
9.7m
\t
125kg
\t
600x550mm
\t
0.75kw
\t
320kg
\t
1375x830x1980mm
\t
SJYL-10
\t
10m
\t
11.7m
\t
100kg
\t
600x550mm
\t
0.75kw
\t
350kg
\t
1400x900x1980mm
\t
SJYL-6
\t
6m
\t
7.7m
\t
200kg
\t
1190x540mm
\t
1.5kw
\t
420kg
\t
1450x890x1980mm
\t
SJYL-7
\t
7m
\t
8.7m
\t
200kg
\t
1190x540mm
\t
1.5kw
\t
480kg
\t
1450x890x1980mm
\t
SJYL-8
\t
8m
\t
9.7m
\t
200kg
\t
1200x600mm
\t
1.5kw
\t
520kg
\t
1450x890x1980mm
\t
SJYL-10
\t
10m
\t
11.7m
\t
200kg
\t
1400x600mm
\t
1.5kw
\t
550kg
\t
1550x890x1980mm
\t
SJYL-12
\t
12m
\t
13.7m
\t
200kg
\t
1500x600mm
\t
1.5kw
\t
640kg
\t
1700x920x1980mm
\t
SJYL-14
\t
14m
\t
15.7m
\t
200kg
\t
1550x600mm
\t
1.5kw
\t
720kg
\t
1750x950x2300mm
\t
SJYL-16
\t
16m
\t
17.7m
\t
200kg
\t
1700x800mm
\t
2.2kw
\t
1180kg
\t
1880x1200x2580mm
\t
SJYL-18
\t
18m
\t
19.7m
\t
200kg
\t
1700x500mm
\t
2.2kw
\t
1400kg
\t
2100x1000x2800mm
\t
SJYL-20
\t
20m
\t
21.7m
\t
200kg
\t
1600x900mm
\t
2.2kw
\t
1800kg
\t
2100x1000x2800mm
Certifications
Detailed Images
Our Service

Pre-Sales Service

* Technical supports and suggestions before you order a machine according to your work place.

* All the machines will be full tested before shipments

* View our Factory.

After-Sales Service

* Operation manual and training how to use the machine.

* Engineers available to service machinery overseas.

* 12 months warranty period and we will provide the consumable parts at cost price after the warranty period

* 24-hour technical support by emails, calling or videos

Packing & Delivery
\t
Packaging
\t
Size
\t
1800(L) * 990 (W) * 2080mm (H)
\t
Weight
\t
880kg
\t



Packaging Details
\t
The normal package is plywood case.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
