Amsky Ausetter 400 Digital Thermal CTP Plate Setter,Computer to Plate
Amsky Ausetter 400 Digital Thermal CTP Plate Setter,Computer to Plate

Amsky Ausetter 400 Digital Thermal CTP Plate Setter,Computer to Plate

Share on (60472667703):


Price:$40,000.00 - $47,000.00

Quantity:


Product Overview

Description


Ausetter 400 series computer to plate







Product Description



Maximum size of plate: 800mm*660mm.
Features: Small volume, high stability and perfect output quality.
UV plate and thermal plate are available for you to lower production cost.
Furthermore, to improve the production efficiency, 32 channels, 48 channel


Thermal CTP Plate Setter.jpg



Technical Specifications





























































































ModelU424U432U448T424T432T448
Exposing MethodExternal Drum
Imaging System24-channel32-channel48-channel24-channel32-channel48-channel
Discrete 400-410nm laserDiscrete 830nm laser
Output Speed16 plates/hour22 plates/hour28 plates/hour16 plates/hour22 plates/hour28 plates/hour
800×660mm 2,400dpi
Plate SizeMax.800×660mm, Min.400×300mm
Exposing SizeMax.800×646mm
Plate TypeUV plate, high-sensitive PS plateThermal plate
Plate Thickness0.15mm-0.3mm
Resolutions2,400dpi
Repeatability±5μm(Continuous exposure over four times on the same plate with a temperature of 23℃ and 60% RH )
InterfaceUSB2.0 / USB3.0 (Recommended option is USB2.0)
Plate LoadingManual place plate, then autoload
Net Weight800KG
Device Size1,900×1,200×1,000mm (W×D×H)
PowerSingle phase:200V-240V; Max power(Peak value):4KW
EnvironmentRecommended temperature: 21-25℃ Allowed temperature: 15-30℃ Humidity: <70%







 After Sales Service

1.two years warranty period

2.provide replacement of accessories

3.provide free technical training and overseas installat ion




Packaging
