Product Overview
Description
Product Description
Properties and Application:
The four kinds of Laminates are made of electrical alkali-free glass cloth impregnated an epoxy resin binder
through hot pressing, which have extremely high mechanical strength, good dielectric loss properties and
good electric strength properties. In addition, FR4 and FR5 sheet has anti-fire property.
Main Specification:
Properties | Unit | Values | ||||
KYEG-10 | KYER-4 | KYEG-11 | KYER-5 | |||
Flexural strength perpendicular to lamination | Room temp. | Mpa | ≥ 340 | |||
155±2℃ | --- | ≥ 170 | ||||
Impact strength parallel to laminations (Notch, Charpy ) | kJ/m2 | ≥ 33 | ||||
Dielectric strength perpendicular to lamination at 90±2℃ in transformer oil 2mm | MV/m | ≥ 11.8 | ||||
Dielectric strength parallel to lamination at 90±2℃ in transformer oil | KV | ≥ 35 | ||||
Insulation resistance after immersion in water * | MEG | ≥1.0x102 | ||||
Loss factor(1MHZ) | - | ≤ 0.04 | ||||
Dielectric Constant(1MHz) |
| ≤5.5 | ||||
Water absorption for 2.0mm thickness | mg | ≤20 | ||||
Thermal Class |
| B | F | |||
Flammability | --- | --- | UL / FV-0 | --- | UL / FV-0 | |
Equal to NEMA |
| G10 | FR4 | G11 | FR5 | |
*Except the Insulation resistance after immersion in Water, other standard values are the same for IEC and NEMA standard.
Product supply:
1, Area: 980mm x 1980mm (38” x 78”); 1020mm x 1220mm (40” x 48”);
1020mmx 2040mm (40” x 80”); 1220mm x 2470mm (48” x 97”)
2, Thickness: 0.2 ~ 50mm
3, Packing: 500~700Kgs / pallet (plywood, plastic, paper)
