7.00mm Nylon Resin Photopolymer Flexo Plate for Corrugated Printing

Product Overview

Description

7.00mm Nylon Resin Photopolymer Flexo Plate for Corrugated Printing

Flexo Plate Description

1)Excellent dot and isolated line reproduction

2)Solid printing performance

3)High latitude of exposure and processing

4)Good ink transfer

5)High impression



Flexo PlateTechnical Parameters



Type		R-700	R-635	R-550
Thickness(mm)		7.00mm	6.35mm	5.50mm
Rigidity(Shore A)		36-33	36-33	35-38
Recommend relief depth(mm)		2.2-3.0	2.2-3.0	2.0-3.0
Image reproduction		3%~95%	3%~95%	3%~95%
Maximum line line/inch		85	85	85
Minimum isolated line		0.3mm (0.0118inch)	0.3mm (0.0118inch)	0.3mm (0.0118inch)
Minimum isolated dot		0.50mm (0.0197inch)	0.50mm (0.0197inch)	0.50mm (0.0197inch)
Suitable ink		Suitable for water and alcohol-based ink, incompatible with oil-based ink, hydrocarbon solvent or the ink containing ethyl acetate of more than 25%
Mainly applicable field		Corrugated board	Corrugated board	Corrugated board, thick board







Flexo Plate Process Parameters



Type		R700
Thickness(mm)		7.00mm
Back exposure(seconds)		160-240
Main exposure(seconds)		12-24
Rinsing(minutes)		9-12
Minimum drying time(hours)		3-4
Detackfying(minutes)		5-8
Post exposure(minutes)		5



1) Platemaking conditions: light of 80 watts (9.7mW/cm2 under 365nm), platesetter temperature 24-30 °C.



2) All the above data is depended on our plate-making device. Due to the different requirements of plate-making device, UV lamp power, relief depth and print image, the above recommended time can be changed appropriately. Customers should test on their own device for optimum plate quality.
