Product Overview

Description



Product Description


Model
JT series
JU series
Type
High Capacity
High Pressure
Size
2 inch, 3 inch, 4 inch, 6 inch, 8 inch, 10 inch, 12 inch
3 inch, 4inch, 6 inch
Max.Flow Rate
1275m3/h
310m³/h
Max.Head
42 m
75 m
Max.Suction Lift
7.6 m
7.6 m
Max.Solids
76 mm
31.75 mm
Max.Rotation Speed
3200 rpm
2350 rpm
Seal Type
Mechanical Sea
Mechanical Seal





Materials of
Construction
Pump housing
Gray Cast Iron,HT200,Stainless Stee
Impeller
Ductileiron,QT450-10,Stainless Stee
Impeller washe
Stainless Steel
Impeller screw
Stainless Steel
Wear plate
A3 Steel
Shaft
40CR,Stainless Stee
Bearing
NSK,Gray Cast Iron,HT200
Mechanical sea
Silicon carbide VS Silicon carbide
Flap Valve
Buna-N




Model
Size
R.P.M.
Max.Flow
Max.Head
Max. Suction Lift
Power
Max.Solids
Gross Weight
(inch)
(r/min)
(m3/h)
(m)
(m)
(hp)
(mm)
(kg)
JT-2
2
1150-2900
46
36
7.6
1-10
44.45
114
JT-3
3
650-2150
107
35
7.6
1-20
63.5
205
JT-4
4
650-1950
163
36
7.6
1-30
76.2
280
JT-6
6
650-1550
330
33
7.6
2-40
76.2
391
JT-8
8
650-1350
600
34
7
7.5-75
76.2
634
JT-10
10
650-1450
775
40
6.7
10-100
76.2
663
JT-12
12
650-1250
1275
42
4.9
20-125
50
1066
JU-3
3
850-2150
85
62
7.6
1.5-25
20.63
225
JU-4
4
850-2150
148
60
5.2
3-40
28.57
297
JU-6
6
850-1950
308
58
4.5
5-75
31.75
437






Appilication


1.Subsurface drainage or mine water drainage
2.Sewage disposal,suitable for sewage disposal plants, hospitals, etc
3.Flood drainage station or civil defense system
4.Agricultural irrigation chemical plants
5.Municipal engineering, sewage work,constructional engineering
6.Sewage collection and discharge in residential community
7.Sewage discharge in hospitals, hotels , etc
8.Centralized and staged disposal system of urban sewage disposal plants
9.Severe industrial and commercial sewage treatment




Main products




Company Information










Packing & Shoipping




FAQ


1. Q: Whats the MOQ ?
A: 1 set for regular product ,the special one we need to discuss.

2. Q : What're your payments ?
A: For small order valve < 4000USD, our customer chose 100% T/T.
For order valve >4000USD, we can accept 30 % T/T inadvance , 70 % should be paid before shipping.

3 . Q : How long is the deliver time ?
A : For the order in stock ,we will deliver goods at once against payment.
For the orders out of stock , the products time is 7 days for bare pump, 25days for electric pump set or diesel engine pump set ,
the deliver time is base on the shipping date and your order by sea.

4. Q: What about the package ?
A : Standard export Plywood case .

5.Q : How is the pump delivered to us ?
A : For small order will be delivered by internation express ,like DHL,TNT ,FEDEX,UPS.
For large order ,it will be delivered by air ,sea ,vehicle or multi-modal transport.

6. Q : How long is the warranty ?
A: According to the internation standards , pump in standard operation is 1 year ,3 monthes for spare parts.
