DLC940E high accuracy flat and thin mini load cell 50kg

Product Overview

Description

DLC940E high accuracy flat and thin mini load cell 50kg



Features:



Model: DLC940E

Category: mini load cell

Range: 50KG

Dimension: 33*30*3.0mm

Material: alloy steel

Application: body scale,kitchen scale,micro-fore test equipment

Characteristic: small platform scale load cell , micro force sensor





SPECIFICATIONS:



Height of white glue:	Below 1.8mm	Output resistance:	1000±10Ω
Comprehensive error:	0.05%FS	Input resistance:	1000±10Ω
Rated output:	1.2±0.2mv/v	Insulation resistance:	≥2000MΩ(100VDC)
Non-linearity:	0.05%FS	Excitation voltage:	3~10VDC
Hysteresis:	0.05%FS	Use temperature:	-10~+60ºC
Repeatability:	0.05%FS	Temp effect on zero:	0.3%FS/10ºC
Creep:	0.1%FS/3MIN	Temp effect on span:	0.1%FS/10ºC
Zero balance:	±0.5mv/v	Defend grade:	IP66
Safe overload:	120%FS	Maximum overload:	150%FS





I am Dita, thank you for visiting our website. Any inquiries, please contact us freely!

We will reply you within 24 hours.

Mobile: 86-18932421732

Email: dita_chen(at)detail-tec.com
skype: manyyear_loadcell

QQ: 22141886





 Price,Package and Service



1. Price : EXW, FOB, C&F

2. Payment: T/T in advance, PayPal, Western Union.

3. Packing : standard export packing, including instructions and certificate

4. Leading time : 3-20 working days according to order quantity

5. OEM available

6. Shipment: Express (FedEx, DHL, UPS & TNT) or forwarder

7. 7 days free replace & 1 year free repair for quality warranty
