1. Adopts Single-Cylinder Structure for Preplastication and Injection.
At present the injection molding machine, if adopting oil cylinder structure, most of them are double injection cylinders parallel to the injection screw, with high energy consumption, heavy weight, more parts, difficult manufacturing, poor synchronization performance, and cause unreasonable stress distribution , etc.
AiBiM company designs a new-model single cylinder injection structure, with simple structure, less parts, light weight, easy manufacture. Single cylinder structure to ensure even stress, low energy consumption, is a high energy-saving product with long lifespan.
2. Optimized the Hydraulic System
* High Energy-Saving
10% more energy-saving compared to same kind servo system (achieved with motor energy efficiency and controller response ability)
* More Stable
Equal cavity calculating exchange (patent technology) to replace traditional shunt synchronization (traditional synchronization is achieved by oil flow adjustment, equal cavity is achieved by designing almost same cavity to make synchronous exchange ), is not affected by any external temperature and load changes, to achieve synchronous permanent stability.
* High Efficient and More Quick
Cancel traditional differential,shunt design, reduce energy losses and decrease oil temperature to improve power efficiency.
Large flow logic valve application to enhance the preplastication ability and stability.
* Longer Lifespan
Adopts original European brand ARGO as hydraulic valve to further enhance the oil route efficiency and lifespan.
