High quality IBC container/tank/tote for washing system
classification
The Technical Date of 1000L HDPE ibc tank of YingHua
Item Specification Tolerance
Item
Specification
Tolerance
Rated Volume(L)
1000
/
Brimful Volume(L)
≥1050
/
Overall Dimension(mm)
1200x1000x1150
±5
Top cap Mouth diameter
142(diameter of thread SLCS 160mm,Pitch 7mm)
±2
Weight for Inner Tank(kg)
15.5
±0.5
Weight for IBC Tank(kg)
58
±2
Valve outside diameter(mm)
50
±1
Wall Thickness(min)
≥1.5mm
/
Outlet Valve(discharge valve)
DN50 ball valve& butterfly valve
/
Height for Pallet(mm)
120
/
Height for forklift holes(mm)
90
/
Length for forklift holes(mm)
795
Other detailed date for our IBC Tank 1000L 1.Model:YH-1000L 2.UNMark:each IBC Tank will mark exclusive UN Uumber 3.Overall dimensiobn:1200*1000*1150mm(±5mm) 4.Max Allowable Weight:2013 kg 5.Tare Weight:58±2kg 6.Allowable Stacking Weight:4056kg 7.Material of inner Receptacle: HDPE 8.Material of outer Casing :Galvanized steel DCD51D 9.Material of pallet: Galvanized steel DC53D 10.Material of seal :EPDM,FKM,Nitrile,PE 11.Valve and Material:Ball Valve DN50 or Butterfly Valve DN 50 12.Stacking Test Weight;4056kg 13.Dropping Test Height:1.9mm 14.Hydraulic Test pressure:100kpa 15.Vibration Test:Amplitude:25±5%mm,Time Duration:1 hour
