Japan Gasoline engine water pump Price in Dubai , Turkey , Saudi Arab , Iraq , UAE, Qatar , Oman
- Category: >>>
- Supplier: Fujian Top Industrial Co. Ltd.
Share on (60483435289):
Product Overview
Description
Product Description
Featuer :
1. Economical, reliable and durable
2. Easy to start, durable OHV, high quality
3. Oil alert to shut down engine automatically when low oil is detected
4. Pump body made of light-weight but strong aluminum alloy
5. Cast iron volute and impeller
6. High-quality ceramic mechanical sealling
7. Max. pump lift of 30m, Max. suction of 8m
| Type | HR15B | HR20 | HR30 | HR40 |
| Outlet Size(mm) | 40(1.5inch) | 50(2inch) | 80(3inch) | 100(4inch) |
| Inlet size(mm) | 40(1.5inch) | 50(2inch) | 80(3inch) | 100(4inch) |
| Speed (rpm) | 3600 | 3600 | 3600 | 3600 |
| Displacement Q.max(m3/h) | 18 | 30 | 60 | 90 |
| Lift H.max(m) | 14 | 25 | 28 | 25 |
| Suction(m) | 6 | 7 | 7 | 7 |
| Engine Model | 154F | 168F | 168F-1 | 188F |
| Engine Type | ||||
| Bore x Stroke(mm) | 54*38 | 68x45 | 68x54 | 88x64 |
| Displacement(cm3) | 87 | 163 | 196 | 389 |
| Compression Ratio | 7.7:1 | 8.5:1 | 8.5:1 | 8.0:1 |
| Max Power Output(HP/rmp) | 2.5/3600 | 5.5/3600 | 6.5/3600 | 13/3600 |
| Max Torque(Nm) | 3.5 | 10.8 | 13.2 | 26.5 |
| Start Model | Recoil and hand -operated | |||
| Air Cleaner | semi-dry | |||
| Fuel Tank Capacity (L) | 1.6 | 3.6 | 3.6 | 6.5 |
| Min Fuel Consumption(g/Kw.h) | 360 | 360 | 360 | 325 |
| Oil Capacity(L) | 0.37 | 0.6 | 0.6 | 1.1 |
| Packing Dimensions (mm) | 450*345*360 | 485x385x380 | 510x385x425 | 635x455x545 |
| G.W/N.W(Kg) | 17 | 22 | 23 | 43/42 |
Packaging & Shipping
