electric household family underfloor heat mat waterproof floor heating systems

Product Overview

Description



Technique data...

Heating cable construction:                                     Twin conductors
Cable shape:                                                                 Round
Diameter:                                                                     4mm
Cold tail:                                                                        2.5m
Deformation strength:                                              Min 600N
Volt:                                                                               120/230/240 V
Conductor insulation:                                                 FEP
Outer sheath:                                                              FEP



Cable Construction:	Twin conductor for electric floor heating mat
Rated Voltage:	230V
Output:	100W/m2 &150W/m2 &200W/m2
Cable spacing:	112mm(100W/m2) & 80mm(150W/m2) & 80mm(200W/m2)
Cable Diameter:	3.6mm
Conductor Insulation:	fluoropolymer
Outer Insulation:	PVC
Max. Ambient Temp.:	85°F(30°C)
Min. Installation Temp.:	40°F(5°C)
Cold lead	2-wire plus ground braid; 2.5m length

Why choose floor heating mat of SENPHUS?

Advantage of our product	Pre-spaced and fixed heating cable
	Suitable for tile and stone floors, carpet, wooden floors
	Simple and trouble free to install
	Benefiting you and the environment
	guaranteed(15-year limited warranty)
	very thin(3.6mm)
	a large range of sizes(100,150,200(w/m)
	a fibreglass mesh not a pre-glued mesh whose the glue will not stick easily
	Dual conductor, only one coldtail,only one end to connect thermostat
	100% earth shielded(wrap the entire cable with a layer of aluminium foil)
	Emits zero EMF
	Mat can be cut and turned
