Onion bag weaving machine leno mesh bag circular loom

Product Overview

Description

Circular Mesh Loom

 Product Description:

This machine is suitable for producing leno bag or mesh bag for various kinds of vegetables and fruits such as carrot, potato, corn, onion, garlic head, orange and apple etc.

This type mesh circular loom with crossing device, frequency inverter, auto stop when warp or weft is broken or weft is finished, digital length counter, it is featured in the compact structure, easy maintenance, low power-consumption and high efficiency.

Compared with the old type mesh circular loom, it saves 90% spare parts and 35% power with more stable running performance, precise warp weaving, the warp can turn 180°. Even if the warp is circle yarn, this machine can show its excellent performance. It is the best ideal replacement of old type mesh circular loom.



Main Technical Parameters:

Item     Type	Shuttle No.(pcs)	Folded Width (40 warps/100mm)	Max. Warp No.(pcs)	Prime Motor Rotational Speed (r/min)	Total Motor Power (Kw)	Capacity (m/h) (40warps/100mm)	Install Size (L×H×W)(mm)	Weight (Kg)
SJ-WY750-4	4	300-750	512	80-110	4	100-240	8500×2500×2900	1900
