Power safe high power 8790160 battery cell lifepo4 battery 10ah 3.2v

Product Overview

Description

Power safe high power 8790160 battery cell lifepo4 battery 10ah 3.2v

Type	Power safe high power 8790160 battery cell lifepo4 battery 10ah 3.2v
Chemistry	Lithium Iron Phosphate
Dimension	8.7mm*90mm*160mm



LiFePO4 Features :



1.The Lithium Iron Phosphate Battery is a type of rechargeable battery based on the original lithium ion chemistry, created by the use of Iron (Fe) as a cathode material.



   It is not yet widely in use.LiFePO4 cells have a higher discharge current, do not explode under extreme conditions and weight less but have lower voltage and energy density



   than normal Li-ion cells.



2.Iron (Fe) is an intrinsically sager cathode material than Cobalt (Co) .The Fe-P-O bond is stronger than the Co-O bond so that when abused (short circuited, overheated, etc)



   the oxygen atoms are much harder to remove. This stabilization of the redox energies also helps fast ion migration. Only under extreme heating, generally over 80°C,



   does breakdown occur which prevents the thermal runaway that LiCoO2 is prone too .





Advantages	Disadvantage
1.Extremely High Rate Capability 2.Safe Lithium Battery 3.Good storage characteristics 4.Good high temperature performance	1.Lower capacity than standard Li-ion 2.3.2V nominal voltage VS 3.6V
Typical Applications
Power tools, Electric vehicle applications, Club car, Emergency lighting high temperature condition use .





Charge /Discharge Chemical Reactions



Typical Performance Characteristics of Lithium Iron Phosphate Batteries
Operational Battery Voltage	3.9 to 2.3 Volts
Special Energy	100 to 120 Wh/Kg
Energy Density	135 to 150 Wh/L
Power Density	2000 to 4500 W/Kg
Continuous Rate Capability	Typical :3C High Rate :30C
Pulse Rate Capability	Up to 100C
Cycle Life At 100% DOD	2000
Calendar Life	3-8 Years
Self Discharge Rate	1-3%/Month
Operational Temperature Range	-20°C to 80°C
Memory Effect	None

Note:Characteristics can change according to improvements in chemistry or special  requirements.





Warnings:



1. Use an original or reliable charger.



2. Do not throw the battery into fire or water.



3. To avoid keeping it at the temperature above 45 degrees or it may cause explosion.



4. Do not pressing it or dropping it from the high altitude.



5. To prevent short circuit, never to put it together with conductors such as keys and coins etc.



6. Keep the battery in a cool dry surrounding if its stand by.
