SAA Electric Flat TPS cable 2.5 Twin and Earth
1. Application
2c+e TPS cable can be used in commercial and industrial area, directly burial or in underground pipeline, particularly suitable for the construction and exported to Australia, USA, Europe and other movable house, containers, refrigerated containers and house cars and other internal installation.
2.Construction
Seven piece copper wire bundles or single bare copper conductor meets the standards of the multinational
Special PVC up to 105 ° C, minimum temperature -40 ° C optional cores insulation
Special PVC up to 105 ° C, minimum temperature of -40 ° C outer sheath, flat type
Electrical properties
Working voltage: 300/500V, 450/750V
Operating temperature range:
Movable Installation: - 5 ° C to +105 ° C, fixed installation: -40 ° C to +105 ° C
Copper conductor & PVC insulated & PVC sheathed Cable(PVC colour: Red & Black & White and according to your requirements)
Insulation: V-90 PVC Sheath: 3V-90 PVC
| ZY009-A | 2*1.5mm²( 7/0.52mm ) | O.D:4.1*6.5mm |
| ZY009-B | 2*2.5mm²( 7/0.68mm ) | O.D:4.6*7.4mm |
| ZY009-C | 2*1.5mm²+1.5mm ( 7/0.52mm ) | O.D:5.4*8.8mm |
| ZY009-D | 2*2.5mm²+2.5mm( 7/0.52mm ) | O.D:5.9*9.7mm |
| ZY009-E | 2*4mm²+2.5mm( 7/0.85mm+7/0.68mm ) | O.D:6.6*10.9mm |
| Australian TPS cable spec | |||
| Size | No./dia. of Conductor | No./Dia.of Earth core | Max outer diameter |
| mm2 | (mm) | (mm) | (mm) |
| 2x1.5 | 2x7/0.52 | / | 4.9x7.8 |
| 2x2.5 | 2x7/0.68 | / | 5.6x9.3 |
| 2x4.0 | 2x7/0.83 | / | 6.2x10.3 |
| 2x6.0 | 2x7/1.04 | / | 6.8x11.6 |
| 2x1.0+1x1.0 | 2x7/0.43 | 7/0.43 | 4.2x6.8 |
| 2x1.5+1x1.5 | 2x7/0.52 | 7/0.52 | 4.6x10.2 |
| 2x2.5+1x1.5 | 2x7/0.68 | 7/0.52 | 5.5x12.8 |
| 2x4+1x2.5 | 2x7/0.83 | 7/0.68 | 6.2x14.1 |
| 2x6+1x2.5 | 2x7/1.04 | 7/0.68 | 6.8x15.3 |
| 2x10+1x4 | 2x7/1.35 | 7/0.83 | 7.8x17.7 |
| 2x16+1x6 | 2x7/1.71 | 7/1.04 | 9.4x21.8 |
