hydraulic press shoe sole cutting machine price
- Category: Apparel Accessories Machinery >>>
- Supplier: Guangdong Honggang Intelligent Equipment Co. Ltd.
Share on (60491066945):
Product Overview
Description
hydraulic press shoe sole cutting machine price
MORE CUTTING MACHINE CLICK FOLLOWS:
1. Hydraulic Swing Arm Cutting Press
2. Hydraulic Plane Cutting Press
3. Double-Side Plane Cutting Press
4. Automatic Feed Cutting Press
5. Hydraulic Traveling Head Cutting Press
Applicable Materials:
This swing arm cutting press machine is used for cutting nonmetal materials such as shoe upper, hand bags, leather, rubber, plastic, cotton, textile, paper, or other similar materials.
It is widely used in shoes making industry.
Feature:
1.Labor saving and simplicity of operation,lower failure rate,better efficiency and high speed of cutting force.
2.Stroke preselecting mechanism,simple,accurate and quick speed regulation for high and low cutting die.
3.Automatic oil pressure lubricating system,making all work pieces automatic lubricated,for the increase of service life.
4.Rocker cutting head rotates freely, the best sight in operation, convenience in choosing materials and high efficiency.
5.Special material cutting head has lubrication system and prolong life, and the best cutting results.
6.Can use doublesided sharp cutting knife, saving the cost of labor and die cutter and pad.
7.Taking advantage of hand wheel to adjust the swing arm subtalar cutting stroke, adjusting operation smoothly and easily.
8.The hands button before cutting, and avoid continuing abuse, high security.
Technicial parameter:
Swing arm clicker Press machine - available in 8T, 10T, 20T, 22T , 25T, 27T.
Full head clicker press- avalible in 25T, 30T, 40T, 50T,...200T, 300T.
Model | HG-D20T | HG-D25T |
Cutting area | 900*430 mm | 900*450 mm |
Motor power | 0.75 kw | 0.75 kw |
Cutting Force | 20 Tons | 25 Tons |
Machine Dimension | 900*980*1410 mm | 1000*1020*1410 mm |
Stroke | 90 mm | 90 mm |
Cutting Plate | 370*450 mm | 500*450 mm |
Net Weight | 865 kg | 1202 kg |
Oil cylinder | Hydraulic | Hydraulic |
Remark: We can make the machine according to your specifically order, for example the color, the motor information ,the working table etc.
Factory show:
Contact:
Looking forward to a good cooperation with you.
