Trailer stub half axle for sale

Product Overview

Description

 Trailer stub half axle for sale

Trailer stub half axle for sale
1.Capacity:1-16Ton
2.Application: Tractors,Small Trailer & Agricultural Trailer & Boat trailer
3.Optional Track length available
4.Optional ABS and automatic slack adjuster available
5.Optional S-cam length
6.Rights of changing product's design and specification are reserved



Stub Axle Specification:

Item No.	Capacity  (T)	Track (mm)	Axle Beam (mm)	Wheel Fixing (mm)	Bearing	Weight (Kg)
LHSA01-AG01	1	200	◊40	4×M14×Φ130×84	30205-20207	15
LHSA03-AG01	3	200	◊50	6×M18×Φ250×160	30206-30209	20
LHSA05-AG01	5	200	◊60	6×M18×Φ250×160	30207-30211	32
LHSA06-AG01	6	200	◊70	6×M18×Φ250×160	30208-30213	43
LHSA08-AG01	8	300	◊80	8×M18×Φ250×160	32211-30215	65



Agrucultural Axle Specification

Item No.	Capacity  (T)	Track (mm)	Axle Beam (mm)	Brake lever position(mm)	Brake Spec.(mm)	Wheel Fixing (mm)	Bearing	Weight (Kg)
		L2				D1×D2	Inner/Outer
LHAH01-AG01	1	1600	◊ 40	no	no	4×M14×Φ130×84	30205-20207	35
LHAH01-AG02	1.5	1600	◊ 45/ο45	no	no	6×1/2″×Φ139.7	LM68149/10 LM12749/10
LHAH02-AG01	2	1600	◊ 50/ο50	no	no	6×1/2″×Φ139.7	25580/20 15123/15245
LHAD03-AG01B	3	1600	◊ 50	470	255×60	6×M18×Φ205×160	30206-30209	65
LHAH05-AG01	5	1600	◊ 60	no	no	6×M18×Φ205×160	30207-30211	60
LHAD05-AG01B	5	1600	◊ 60	470	255×60	6×M18×Φ205×160	30208-30211	100
LHAH06-AG01	6	1600	◊ 70	no	no	6×M18×Φ205×160	30208-30213	85
LHAD06-AG01B	6	1600	◊ 70	470	300×60	6×M18×Φ205×160	30208-30213	120
