Syrups Mixing Tank Emulsifying Tank
- Category: >>>
- Supplier: Shanghai Youcan Beverage Machinery Co. Ltd.
Share on (60493466306):
Product Overview
Description
Syrups Mixing Tank Emulsifying Tank
Product Description
Tank Specification:
- steam heating type / how water heating type / can be cooled by tap water.
- stainless steel jacket.
- made of three layer with temperature insulation.
- agitation scrapers sweeping the inner surface of the mixing tank.
- mixing capacity from 500Liter to 20,000Liter.
- or mixing capacity from 100Gallon to 5000Gallon.
- mixing speed can be 36rpm, 750rpm, or adjustable speed, the speed can be variable.
Product Advantage:
- Made of stainless steel, suitable for food and beverage production.
- Designed with jacket, allowed for hot water or steam heating, as well as tap water cooling.
- With temperature gauge <range 0~150 centigrade>.
- With glass level meter.
- CIP friendly.
Field of Application:
- Can be used as liquid storage tank, blending vessel, temporary storage tank, buffer tank and water storage tank etc.
- Ideal for food, dairy processing, fruit juice beverages, pharmaceutical, beer and wine brewing, chemical and biological engineering industries.
Construction & Configuration:
- Double wall contstruction
- The two walls make up the jacket which allowed hot water and cooling water pass through.
- Conical bottom, easy to discharge
- Sealed top, sanitary and prevent dirt in air fly in the tank effectively
- Interior welds are ground smooth, passivated and polished. Transitional areas are made into arc shaped blends to ensure no dead zones of sanitation.
- Various types of CIP cleaners.
- Vortex breaker / baffles.
- Liquid level probe and level controller (as per customer requirements.)
- Temperature probe (as per customer requirements.)
- Quick opening manway.
- Sanitary breathing cover to keep out flies and insects.
- Agitator (as per customer requirements.)
- Impellers available for different applications: flat blade, bar turbine, anchor, propeller three blades, axial flow four blades, axial flow three blades, double spiral, etc.;
- Dismountable inlet pipe assembly.
Technical Parameters
Technical Parameters:
| Working Volume (L) | Total Height (mm) | Diameter of Inlet & Outlet (mm) | Motor Power (kw) |
| 500 | 2,450 | 38 | 0.55 |
| 600 | 2,550 | 38 | 0.55 |
| 700 | 2,550 | 38 | 0.55 |
| 800 | 2,700 | 38 | 0.55 |
| 900 | 2,700 | 38 | 0.55 |
| 1,000 | 2,850 | 51 | 0.75 |
| 1,500 | 3,050 | 51 | 0.75 |
| 2,000 | 3,110 | 51 | 1.1 |
| 3,000 | 3,700 | 51 | 1.5 |
| 4,000 | 3,700 | 51 | 1.5 |
| 5,000 | 3,950 | 51 | 2.2 |
| 6,000 | 4,000 | 51 | 2.2 |
| 7,000 | 4,250 | 51 | 2.2 |
| 8,000 | 4,700 | 51 | 3 |
| 9,0000 | 4,750 | 51 | 3 |
| 10,000 | 4,750 | 51 | 3 |
| 12,000 | 5,300 | 51 | 4 |
| 15,000 | 5,400 | 63 | 4 |
| 20,000 | 6,100 | 63 | 5.5 |
* Note:
- We also can supply customized tanks meeting your unique requirements, please feel free to contact us.
- Common rotation speed 35, 43, 60 stepless Speed reducer or Dual-speed reducer are also available.
- Insulation layer: 60mm.
- For other details and customized tanks, please contact us at WhatsApp/Cell: +86 138 1711 5848.
